Summary of Contents for Nordson Mastic Gun
- Page 1 Mastic Gun Customer Product Manual Part 1040769A Issued 2/04 NORDSON CORPORATION • AMHERST, OHIO • USA...
-
Page 2: Table Of Contents
555 Jackson Street Amherst, OH 44001 Notice This is a Nordson Corporation publication which is protected by copyright. Original copyright date 2004. No part of this document may be photocopied, reproduced, or translated to another language without the prior written consent of Nordson Corporation. The information contained in this publication is subject to change without notice. -
Page 3: Safety
A jet of high-pressure fluid can cut like a knife and cause serious bodily Use of Nordson equipment in ways other than those described injury, amputation, or death. Fluids penetrating the skin can also in the documentation supplied with the equipment may result in cause toxic poisoning. -
Page 4: Fire Safety
Make sure heat more information. If you must use halogenated hydrocarbon monitoring and limiting devices are working properly. solvents, contact your Nordson representative for information Provide adequate ventilation to prevent dangerous about compatible Nordson components. concentrations of volatile particles or vapors. Refer to local codes or your material MSDS for guidance. -
Page 5: Installation
5. If the nozzle becomes blocked during operation, refer TRIGGER SAFETY to the Clearing a Blocked Nozzle procedure in the UNLOCK Troubleshooting section. LOCK Note: Portion of trigger not shown for clarity. Figure 2 Mastic Gun Part 1040769A E 2004 Nordson Corporation... -
Page 6: Valve Stem Adjustment
Tighten the stem nut to the torque specification listed the problem with the information given here, contact your on Figure 4. local Nordson representative for help. 5. Using a screwdriver, turn the spring retainer screw as needed to close the valve stem. -
Page 7: Repair
5. Remove the seal retainer (10) from the gun body and 6. Using a wrench on the fluid tube hex, connect the replace the seal. material hose to the gun. Part 1040769A E 2004 Nordson Corporation... -
Page 8: Parts
Mastic Handgun Parts To order parts, call the Nordson Customer Service Center or your local Nordson representative. LUBRICATION POINTS Item A: Apply lithium-base grease. TORQUE SPECIFICATIONS Item B: Apply lithium-base grease to threads. Items 3 and 10: 11–14 N•m (100–125 in.-lb) Item C: Apply low-strength anaerobic sealant (blue).
