181-VL
Quick Setup
Instructions
WARNING: Electrical and plumbing
connections need to be made by a
qualified service technician and
comply with all available Federal, State
and Local Health, Electrical, Plumbing
and Safety codes.
HARD WIRE
FOUR WIRE
POWER SUPPLY
HOT
NEUTRAL
GROUND
1
DRAIN HOSE
COLD WATER
2
LINE
STEP
1
1"AIR GAP
FLOOR DRAIN
Connect the drain hose to floor drain. The floor
drain must have a 1 inch air gap between drain
hose and floor drain.
PN: 10130.00
181-VL REAR VIEW
STEP
2
Connect dishmachine to cold water source.
TUBE
3
STIFFENER
CHEMICAL
TUBING
RED
BLUE
STEP
3
RED
BLUE
Insert tube stiffener with chemical tubing into
corresponding chemical dispensers.
