Assembly Manual
Read the operator's manual entirely. When you see this symbol, the
subsequent instructions and warnings are serious - follow without
exception. Your life and the lives of others depend on it!
Illustrations may show optional equipment not supplied with standard unit.
ORIGINAL INSTRUCTIONS
© Copyright 2018
Table of Contents
Index
Manufacturing, Inc.
www.greatplainsmfg.com
Printed 2018-10-22
Index
Turbo Max
3.0M
TP-69358
EN
588-154Q-ENG
Advertisement
Table of Contents
Related Manuals for GREAT PLAINS Turbo Max 3.0M
Summary of Contents for GREAT PLAINS Turbo Max 3.0M
- Page 1 Table of Contents Index Assembly Manual Turbo Max 3.0M Manufacturing, Inc. www.greatplainsmfg.com Read the operator’s manual entirely. When you see this symbol, the subsequent instructions and warnings are serious - follow without exception. Your life and the lives of others depend on it! TP-69358 Illustrations may show optional equipment not supplied with standard unit.
- Page 2 Table of Contents Index Table of Contents Index...
-
Page 3: Table Of Contents
Great Plains Manufacturing, Inc. assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein. Great Plains Manufacturing, Inc. reserves the right to revise and improve its products as it sees fit. - Page 4 3.0M TM Table of Contents Index Great Plains | 588-154Q-ENG | 2018-10-22 Table of Contents Index...
-
Page 5: Introduction
3.0M Turbo-Max Table of Contents Index Introduction Introduction Great Plains’ Turbo-Max is a pull-type unit designed for tilling and working soil. Every Turbo-Max we build is designed and built with care using only quality materials. best installation experience, read this manual and follow all instructions carefully. -
Page 6: Safety Information
4. Replace chain if any links or end fittings are broken, stretched or damaged. 5. Do not use safety chain for towing. Great Plains | 588-154Q-ENG | 2018/10/22 Table of Contents Index... - Page 7 Use a safety cage if available. 2. When removing and installing wheels, use wheel- handling equipment adequate for weight involved. Great Plains | 588-154Q-ENG | 2018/10/22 Table of Contents Index...
- Page 8 4. Turn lockout valve and wing lock levers to locked position to prevent the wings from lowering. 5. Install transport locks to relieve pressure on hydraulic hoses. 6. Detach the tractor. Secure the implement using blocks and supports. Great Plains | 588-154Q-ENG | 2018/10/22 Table of Contents Index...
- Page 9 10. Watch out for wires, trees, etc., when folding and raising the implement. 11. Turning tractor too tight can cause hitched implement to ride up on wheels. This can result in injury or equipment damage. Great Plains | 588-154Q-ENG | 2018/10/22 Table of Contents Index...
-
Page 10: Assembly
Reduce risk complications by first unloading the gangs, finishing attachments, and other miscellaneous components. Place these components well out of the maneuvering area needed for unloading the Turbo-Max frames. Great Plains | 588-154Q-ENG | 2018/10/22 Table of Contents Index... -
Page 11: Removing Machine Components From Container
Un- rack tires, crated tires, and all machine frames. Use a hoist or forklift to move large components. Set the smaller drag frames aside to keep clear of assembly area. Great Plains | 588-154Q-ENG | 2018/10/22 Table of Contents Index... -
Page 12: Gang Assembly - Center Frame
(13). This hardware will be in place on the center frame 6. Secure hydraulic cylinder to front gang bar using clevis pin (16), cotter pin (2), and washer (15). Great Plains | 588-154Q-ENG | 2018/10/22 Table of Contents Index... -
Page 13: Center Axle (Braked Option)
1. With machine raised on stands, slide the axle (1) underneath the center frame using a hoist (or appropriate forklift). 2. Attach axle (1) to torque tube using ” bolts (2), lock washers (3), and nuts (4). 3. Install wheel and tire assemblies. Great Plains | 588-154Q-ENG | 2018/10/22 Table of Contents Index... -
Page 14: Center Transport Hubs (Non-Braked Option)
2. Attach hub mount (1) to torque tube using ” bolts (2), lock washers (3), and nuts (4). 3. Slide hub shaft into the mount and secure with ” bolts, lock washers, and nuts. Great Plains | 588-154Q-ENG | 2018/10/22 Table of Contents Index... -
Page 15: Trusses & Level Bar
See “Torque Values Chart” on page 21. to the center frame. See “Weight Package Assembly (optional)” on page 18. Figure 2 42982 Trusses & Level Bar Great Plains | 588-154Q-ENG | 2018/10/22 Table of Contents Index... -
Page 16: Hitch
17. You may now connect the hydraulic hoses at the valves located on the center frame. front of hitch with x 1 Gr. 5 bolt (10), lock washer and flat washer. Figure 3 42983 Hitch Great Plains | 588-154Q-ENG | 2018/10/22 Table of Contents Index... -
Page 17: Depth Stop & Angle Gauge
24. Tighten all bolts with lock nuts snug, but do not torque. The rest of the bolts may be tightened to specs, See “Torque Values Chart” on page 21. Figure 4 Depth Stop & Angle Gauge 43907 Great Plains | 588-154Q-ENG | 2018/10/22 Table of Contents Index... -
Page 18: Attach Hose Clamps And Hose Wraps
Only trained personnel should work on system hydraulics. Hydraulic Hose Hookup Great Plains hydraulic hoses are color coded to help you hookup hoses to your tractor outlets. Color Hydraulic Function... -
Page 19: Purging Hydraulic System
30. Retract and extend the gang system (1) (Red Handles) several times to purge air from system. Watch for leaks and re-tighten fittings if necessary. Figure 7 43935 Gang Cylinder Purging Great Plains | 588-154Q-ENG | 2018/10/22 Table of Contents Index... -
Page 20: Rolling Harrow And Reel (Option)
Be sure to reinstall the quick pins to keep the adjustment pin in place. Great Plains | 588-154Q-ENG | 2018/10/22 Table of Contents... -
Page 21: Reel Following Rolling Harrow
Be sure to reinstall the quick pins to keep the adjustment pin in place. Great Plains | 588-154Q-ENG | 2018/10/22 Table of Contents... -
Page 22: Weight Package Assembly (Optional)
20. Torque x 2 Gr. 8 bolts (1) to 375 ft lbs to be sure bolts do not work loose and cause damage to machine. Figure 9 43106 Level Bar Great Plains | 588-154Q-ENG | 2018/10/22 Table of Contents Index... -
Page 23: Lights
All decals should be installed on the machine prior to shipping. If decals are not placed on machine in full or in part, refer to the machine’s operator and parts manual for decal placement. Great Plains | 588-154Q-ENG | 2018/10/22 Table of Contents... -
Page 24: Completing Setup
5. If machine has an optional finishing attachment or rear hitch, refer to the “Parts Manual” for parts break down and attachment layout drawings of this manual. Be sure to consult the operating instructions, in “Operator’s Manual”, for the first time field adjustments before going to the field. Great Plains | 588-154Q-ENG | 2018/10/22 Table of Contents Index... -
Page 25: Appendix - Reference Information
Gang Bolt Torque 1 ”-5 850 Foot-pounds (165 lbs on 5’ cheater). Rolling Harrow Spike Bolt 1 ”-6 650-750 Foot-pounds (175 lbs on 4’ cheater). Wheel Bolt Torque Values ”-18 (85-100ft-lbs) Great Plains | 588-154Q-ENG | 2018/10/22 Table of Contents Index... -
Page 26: Tire Inflation Chart
16-22 12-16 -18 ORB w/jam nut 24-33 18-24 -18 ORB straight 37-53 27-39 -16 JIC -16 ORB w/jam nut 27-41 20-30 -16 ORB straight 37-58 27-43 Great Plains | 588-154Q-ENG | 2018/10/22 Table of Contents Index... -
Page 27: Hydraulic Lift Layout
3.0M Turbo-Max Table of Contents Index Appendix - Reference Information Hydraulic Lift Layout TP-69360 Great Plains | 588-154Q-ENG | 2018/10/22 Table of Contents Index... -
Page 28: Hydraulic Gang Angle Layout
3.0M Turbo-Max Table of Contents Index Appendix - Reference Information Hydraulic Gang Angle Layout TP-69361 Great Plains | 588-154Q-ENG | 2018/10/22 Table of Contents Index... -
Page 29: M Tm Machine Layout
3.0M Turbo-Max Table of Contents Index Appendix - Reference Information 3.0M TM Machine Layout TP-69366 Great Plains | 588-154Q-ENG | 2018/10/22 Table of Contents Index... -
Page 30: Heavy Reel Following Rolling Harrow Layout
3.0M Turbo-Max Table of Contents Index Appendix - Reference Information Heavy Reel Following Rolling Harrow Layout TP-69143 Great Plains | 588-154Q-ENG | 2018/10/22 Table of Contents Index... - Page 31 20 mph ..........4 hydraulic lift layout .......23 30 kph ..........4 3.0M TM Machine .......25 leaks .............3 lights .............3 maintenance safety ......4 medical assistance ......3 National Pipe Thread ......22 Great Plains | 588-154Q-ENG | 2018-10-22 Cover Table of Contents...
- Page 32 3.0M TM Table of Contents Index Great Plains | 588-154Q-ENG | 2018-10-22 Table of Contents Index...
- Page 33 Table of Contents Index Table of Contents Index...
- Page 34 Table of Contents Index Great Plains, Mfg. 1525 E. North St. P.O. Box 5060 Salina, KS 67402...
