Read the operator's manual entirely. When you see this symbol, the
subsequent instructions and warnings are serious - follow without
exception. Your life and the lives of others depend on it!
Illustrations may show optional equipment not supplied with standard unit.
ORIGINAL INSTRUCTIONS
© Copyright 2020
Table of Contents
Index
Operator Manual
Turbo Max (S/N C2411H+)
3500TM & 4000TM
Manufacturing, Inc.
www.greatplainsmfg.com
Printed 2020-07-30
Index
43054
EN
586-537M
