- Page 1 TWR-K60N512-KEIL Quick Start Guide For the Freescale Kinetis K60 family of microcontrollers Tower System Development Board Platform Arrow.com. Downloaded from...
- Page 2 Quick Start Guide freescale.c Get to Know the TWR-K60N512-KEIL Board Primary Connector Potentiometer Infra-Red SD C Touch TWRPI Sock Socket General-Purpose Tower Plug-In (TWRPI) Socket LED/Touch Buttons SW3 (Reset) E1–E4 VBAT Power/OSJTAG Batte Mini-B USB MK60N512 Holde Connector VMD100 Microcontroller Secondary MMA7660 Figure 2: Back Side of TWR-K60N512-KEIL Board...
- Page 3 Step-by-Step Installation Instructions In this Quick Start Guide, you will learn how to set up the TWR-K60N512-KEIL board and run the default demonstration. Install the Software Tilt the Explore Further with the and Tools Board Keil Quick Start ® ® Guide Install the P&E Micro Kinetis Tower Toolkit Tilt the board side to side to...
- Page 4 Quick Start Guide freescale.c Jumper Options The following is a list of all the jumper options. The default installed jumper settings are shown in shaded boxes. Jumper Option Setting Description Jumper Option Setting Description Connect onboard 3.3 V supply to MCU Connect on-board 5 V supply to JTAG port (supports p JTAG Board MCU Power...
- Page 5 Go to freescale.com/towerkeil to find pertinent information for the TWR-K60N512-KEIL module, including: • TWR-K60N512N-KEIL User’s Manual • TWR-K60N512N-KEIL Schematics Support Visit freescale.com/support for a list of phone numbers within your region. Warranty Visit freescale.com/warranty for complete warranty information. To learn more about the TWR-K60N512-KEIL and other Freescale Kinetis microcontroller products, visit freescale.com/towerkeil, freescale.com/Kinetis...
