"P" Table and "P" Table w/ Conference End
CATALOG No:
C383R02
NOTE: Please count and inspect all pieces before disposing of any carton or packing materials.
COMPONENTS:
REF. #
QTY.
1
1
2
1
3
1
4
1
5
1
6
1
7
1
HARDWARE BAG (PART No. A7807)
REF. #
QTY
E1
25
E2
8
E3
8
E4
4
E5
2
E6
2
ASSEMBLY INSTRUCTIONS
R.H. SHOWN
When ordering components, specific color and/or size information may be required.
Contact a Mayline Customer Service Representative.
DESCRIPTION
WORK SURFACE
MODESTY PANEL
LEG
LEG (extra mounting holes)
POST LEG
JOINING PLATE
MODESTY PANEL
DESCRIPTION
#10 X 3/4 SCREW
#10-24- X 3/8 SCREW
#10-24 KEPS NUT
GLIDE
CABLE CLAMP
SCREW, #6 X 3/8 PPHTS
L.H. SHOWN
PART No.
CALL~~**
B7485**
** Denotes Color Code
C733**
~~Denotes Size
C734**
B5185**
B7522
B7892**
*for individual part, order that part number
PART No.
X11*
X147*
T2*
Q630*
F191*
X5126*
(1)
CATALOG No:
C383L01
1-800-822-8037
