ASSEMBLY INSTRUCTIONS
CS
II
CATALOG No:
C625
C626
C627
C635
C636
C637
C645
C646
C647
NOTE: Please count and inspect all pieces before disposing of any carton or packing materials.
COMPONENTS:
REF. #
QTY.
1
1
2
1
3
1
HARDWARE BAG (PART No. A7646)
REF. #
QTY
E1
12
E2
2
FREESTANDING PENINSULA
When ordering components, specific color and/or size information may be required.
Contact a Mayline Customer Service Representative.
DESCRIPTION
WORK SURFACE
LEG
POST LEG
DESCRIPTION
#10 X 3/4 SCREW
GLIDE
(1)
1-800-822-8037
PART No.
CALL~~**
** Denotes Color Code
CALL~~**
~~Denotes Size
B5185
*for individual part, order that part number
PART No.
X11*
Q444*
