NOTE: Please count and inspect all pieces before disposing of any carton or packing materials.
COMPONENTS:
REF. #
QTY.
1
1
2
4
3
0 / 1
HARDWARE BAG (PART No. A7621)
REF. #
QTY
E1
38
E2
6
E3
6
E4
2
ASSEMBLY INSTRUCTIONS
CS
II
When ordering components, specific color and/or size information may be required.
Contact a Mayline Customer Service Representative.
DESCRIPTION
BRIDGE WORK SURFACE
CONNECTOR PLATE
MODESTY PANEL (OPTIONAL)
DESCRIPTION
#10 X 3/4 SCREW
#10-24- X 3/8 SCREW
#10-24 KEPS NUT
CABLE CLAMP
BRIDGE
PART No.
CALL~~**
B7522
CALL~~**
*for individual part, order that part number
PART No.
X11*
X147*
T2*
F191*
(1)
1-800-822-8037
** Denotes Color Code
~~Denotes Size
Advertisement
Table of Contents
Related Manuals for Mayline CSII BRIDGE
Summary of Contents for Mayline CSII BRIDGE
- Page 1 ASSEMBLY INSTRUCTIONS BRIDGE NOTE: Please count and inspect all pieces before disposing of any carton or packing materials. When ordering components, specific color and/or size information may be required. COMPONENTS: Contact a Mayline Customer Service Representative. 1-800-822-8037 REF. # QTY. DESCRIPTION PART No.
- Page 2 NOTE: DO NOT MOVE work station once the Bridge has been attached. ASSEMBLY PROCEDURE: Bridge without Modesty Panel 1. Locate the pre-drilled Connector Plate holes on the underside of the Main work surface and on the adjacent work surface which are to be joined by the Bridge. Attach the four Connector Plates (2) to these work surfaces with four Screws (E1) per plate.
- Page 3 NOTE: DO NOT MOVE work station once the Bridge has been attached. ASSEMBLY PROCEDURE: Bridge with Full Height or 2/3 Height Modesty Panel 1. Locate the pre-drilled Connector Plate holes on the underside of the Main work surface and on the adjacent work surface which are to be joined by the Bridge.
