Cypress Semiconductor CY4672 PROC Quick Start Manual

1
Remove the CY4672 PRoC LP Reference
Design Kit bridge dongle, keyboard, and
mouse from the package.
3
Power the mouse and keyboard with two
AA batteries each.
5
Press the bind button on the bridge; the red
LED blinks. Press the bind button on the key-
board to bind it with the bridge. The mouse
and keyboard work smoothly with the PC.
CY4672 PR C™ LP REFERENCE DESIGN KIT
O
QUICK START GUIDE
2
Connect the bridge dongle to the PC. The
bridge enumerates as a human interface
device (HID).
4
Turn on the mouse. Press the bind button on
the bridge; the red LED blinks. Press the bind
button on the mouse to bind it with the bridge.
6
Insert the CY4672 kit CD. Install PSoC
Designer and PSoC Programmer.
