DREAMS Bond Oak-High Foot End-Linen Assembly Instructions

Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

Bond Oak-High Foot End-Linen
Assembly Instructions
Before you
Start, here
are some
helpful
advices.
Revision number 1/1
1. We suggest you spend a short time reading through this leaflet and then follow
the simple step by step instructions.
2. If you follow the instructions carefully the end result should be worth the effort.
3. Do not discard any of the packaging until you have checked that you
have all the parts and the pack of fittings.
4. Assemble this product on a carpet.
5. To ensure an easier assembly, we strongly advise that all fittings are only
finger tightened during initial assembly. Only upon completion of
theassemblyshould all fixing points be fully tightened.
6. We recommend a periodic check on all fixing points to make sure they remain
fully tightened.
7. Keep glue and fittings out of children's reach.
In the unlikely event that this product has missing or damaged parts, please call
03442920000to obtain spares
Page 1 of 5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bond Oak-High Foot End-Linen and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DREAMS Bond Oak-High Foot End-Linen

Summary of Contents for DREAMS Bond Oak-High Foot End-Linen

  • Page 1 Bond Oak-High Foot End-Linen Assembly Instructions Before you 1. We suggest you spend a short time reading through this leaflet and then follow the simple step by step instructions. Start, here 2. If you follow the instructions carefully the end result should be worth the effort.
  • Page 2 PARTSFittings M6× 50 mmx6pcs M6×6pcs 4mm Allen key × 2pcs Metal Washer(M6)x6pcs Screw x35mmx 1pcs NO. PART LIST (1) Headboard 5mm Allen key × 1pcs (2) Footboard (3) Side Rails Support Leg Revision number 1/1 Page 2 of 5...
  • Page 3 ASSEMBLY STEP1 (1).Use the Side Rails (3) is mounted to the Headboard （1）、 Footboard（2），with a Allen Key (F) to lock the bolt Revision number 1/1 Page 3 of 5...
  • Page 4 Both slats on "step 2" and "step 3" can be assembled to the bedstead. you can make a choice between the two slats. OPTION"A": DREAMS FIXED WOOD SLATS (1) Carefully locate the slats onto the unit, as step 2: Use bolt (A), washer (D) and...
  • Page 5 ASSEMBLY STEP 3 OPTION"B":DREAMS SPRUNG SLATS (1) Use the bolt to fix support onto slat frame. Please note that these bolts are to be found inside the slat frame box. (2) Carefully locate the slats onto the unit. (3) Use bolt (A) and JCN nut (B) to fix the unit using Allen Key (C).
