DREAMS BRUGES KING B/S Assembly Instructions Manual

Table of Contents

Download this manual

Assembly Instructions

Minimum No. of people

Recommended to assemble

This product.

Approx assembly time:

NOTE: It will require two people to assemble this bed. Assembly should be carried out in the room that

the bed will be used in.

Before you

Start, here

is some

helpful advice

BRUGES KING B/S

1. We suggest you spend a short time reading through this leaflet and then

follow the simple step by step instructions.

2. If you follow the instructions carefully the end result should be worth the effort.

3. Do not discard any of the packaging until you have checked that you

have all the parts and the pack of fittings.

4. Assemble this product on a carpet.

5. To ensure an easier assembly, we strongly advise that all fittings are only

finger tightened during initial assembly. Only upon completion of the assembly

should all fixing points be fully tightened.

6. We recommend a periodic check on all fixing points to make sure they remain

fully tightened.

7. Keep glue and fittings out of children's reach.

In the unlikely event that this product has missing or damaged parts, please call

0870 3333 612

to obtain spares

1 of 6

Table of Contents

Need help?

Do you have a question about the BRUGES KING B/S and is the answer not in the manual?

Page 1 BRUGES KING B/S Assembly Instructions Minimum No. of people Recommended to assemble This product. Approx assembly time: NOTE: It will require two people to assemble this bed. Assembly should be carried out in the room that the bed will be used in.
Page 2 Component parts and fittings contained in the box PARTS Fittings（A） Connector 4pcs Connecting bolt 4pcs 1 piece M8 Nut 4pcs 1 piece 2 pieces 8 Spring Washer 4pcs 1 piece Spanner 2 pieces M6x35mm Bolt 6pcs 1 piece 1 piece M6 JCN Nut 6pcs 4 pieces...
Page 3 ASSEMBLY STEP 1 1) Attachment of wooden leg to Head/footboard. STEP 2 1) Attachment of center rails to side rails. STEP 3 1) Attachment of short rails to center rails. 3 of 6...
Page 4 ASSEMBLY STEP 4 Attachment of side rails to Head/footboard. STEP 5 Attachment of side panel onto the back panel. STEP 6 Slide the bottom panel into the unit. 4 of 6...
Page 5 ASSEMBLY 1) Assembly of the frong panel onto side STEP 7 frame. ng panel onto 1) Slot in the Drawers. STEP 8 NOTE: STEP 9 Both slats on “step 9---step 12” can be assembled to the bedstead. Please follow the correct procedure for the slat system which you have chosen.
Page 6 ASSEMBLY STEP 10 1) Use the pcs bolts, supplied with the slat frame to fix the leg onto the slats frame. STEP 11 1) Carefully place the slat frame onto the bed. 2）Use bolt (F) and JCN nut (G) to fix the slat frame onto the bed.
