SABINA BED
Minimum No.of people
recommended to assemble
this product
Approx assembly time
Before you
start,here
is some
helpful advice
ASSEMBLY INSTRUCTION
2
45
minutes
We suggest you spend a short time reading through this leaflet and
1.
then follow the simple step by step instructions.
If you follow the instructions carefully the end result should be worth
2.
the effort.
Do not discard any of the packaging until you have checked that you
3.
have all the parts and the pack of fittings.
To ensure an easier assembly, we strongly advise that all fittings are
4.
only finger tightened during initial assembly. Only upon completion of
the. Assembly should all fixing points be fully tightened.
We recommend a periodic check on all fixing points to make sure they
5.
remain fully tightened.
6.
In the unlikely event that this product has missing or damaged parts,
7.
please call 0844 292 0000 to obtain spares
SMALL DOUBLE ....................(Solid slats)
DOUBLE
KING
................(Sprung slats)
................... (Solid slats)
............... (Sprung slats)
................... (Solid slats)
................(Sprung slats)
Advertisement
Related Manuals for DREAMS SABINA BED
Summary of Contents for DREAMS SABINA BED
- Page 1 SMALL DOUBLE ....(Solid slats) ....(Sprung slats) DOUBLE ....(Solid slats) ....(Sprung slats) KING ....(Solid slats) ....(Sprung slats) SABINA BED ASSEMBLY INSTRUCTION Minimum No.of people recommended to assemble this product Approx assembly time minutes Before you We suggest you spend a short time reading through this leaflet and then follow the simple step by step instructions.
- Page 2 PARTS 1(1 piece) 3(2 pieces) 4(1 pieces) 5(2 pieces) 2(1 piece) FITTINGS Flat washer ∅19 x 8pcs M6 x 20 mm x 6pcs. M6 x 45mm x 8pcs. Allen key 4mm x 2pcs. Note: The following fittings will be found in the box which contains the Sprung Frame, NOT with the bed frames Assembly Kit.
- Page 3 Assembly ASSEMBLY ITEM #: SABINA BED Fix the side rails "3" to the headboard "1" and STEP 1 footboard "2". Tighten the bolts which are pre-fitted on Head & Foot End using allen key "D". Identify the slat system you have purchased...
- Page 4 Sprung slat system Turn to step 6,7 Attach central support "4" to support feet "5". STEP 2 Use bolts "A" and flat washers "C", tighten using allen key "D".
- Page 5 Place the fixed central support "4" onto the support STEP 3 block on headboard "1" and footboard "2". IMPORTANT Once the feet have been STEP 4 assembled and attached, they should be adjusted to ensure they do not touch the floor, (10mm above the floor) to allow for movement once the mattress is placed on the bed frame.
- Page 6 STEP 5 Standard wooden slat system Place the fixed wood slats onto the slat holders on side rails "3". Fix the slats at both ends and the middle using bolts "A", sleeve nuts "B" and flat washers "C",tighten with allen key "D". Sprung slat system STEP 6 Fix the center legs to the...
- Page 7 Adjust leg height to suit bed frame 10mm Please note: the center bar "4" and wooden support STEP 7 feet "5"can be probably disposed if choosing sprung slat frame Turn the metal slat frame falling upward and carefully lower the slat frame into the bed.
