Crimping Details
SeaStar Slide Cylinders
7.25"
LARGE HOLE
SeaStar Pivot & Tournament
5.25"
LARGE HOLE
BayStar Cylinders
LARGE HOLE
© 2007 Marine Canada Acquisition Inc. DBA SEASTAR SOLUTIONS 3831 No. 6 Road, Richmond, B.C. Canada V6V 1P6
INSTALLATION INSTRUCTIONS
Copy Part# 296800, Rev. C, 12/2014
OUTBOARD CYLINDER
GROUNDING STRAP
Part # HA5477
The Grounding Strap Kit is designed to provide added protection
against corrosion caused by stray current. This is designed for
use on SeaStar and BayStar front mounting outboard cylinders.
1. Using figures A, B & C determine your style of steering cylinder.
2. Measuring from the large hole, crimp terminal as per the length
noted next to your cylinder style. Crimp terminal to ground strap
using pliers.
A
CRIMP/FOLD UP TO SECURE TO GROUND STRAP
B
Cylinders
CRIMP/FOLD UP TO SECURE TO GROUND STRAP
C
NOT USED
Page 1 of 2
SMALL HOLE
SMALL HOLE
SMALL HOLE
Fax: 604.270.7172
Web: www.seastarsolutions.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Seastar Solutions HA5477
Summary of Contents for Seastar Solutions HA5477
- Page 1 LARGE HOLE CRIMP/FOLD UP TO SECURE TO GROUND STRAP SMALL HOLE BayStar Cylinders NOT USED LARGE HOLE SMALL HOLE © 2007 Marine Canada Acquisition Inc. DBA SEASTAR SOLUTIONS 3831 No. 6 Road, Richmond, B.C. Canada V6V 1P6 Fax: 604.270.7172 Web: www.seastarsolutions.com...
-
Page 2: Installation Procedure
ON ENGINE POWER HEAD OR MID-SECTION DISCARD THIS WASHER CYLINDER SHAFT NUT GROUND STRAP Figure E. BayStar Cylinders, Configuration C. © 2007 Marine Canada Acquisition Inc. DBA SEASTAR SOLUTIONS 3831 No. 6 Road, Richmond, B.C. Canada V6V 1P6 Fax: 604.270.7172 Web: www.seastarsolutions.com...
