ESI Outdoor Unit Installation Instruction
NOTE: Appearance of unit may vary.
The IoT gateway does not ship with outdoor unit.
Visit www.ecoer.com to get IoT installation guide.
Installation must be performed in accordance with
the requirements of NEC and CEC by authorized
personnel only.
All phases of this installation must comply with National, State and Local Codes.
IMPORTANT
This document is customer's property and is to remain with this unit. Please return it to customer
with service information upon completion of work.
These instructions do not cover all variations in systems or provide for every possible contingency
to be met in connection with the installation. Should further information be desired or should
particular problems arise which are not covered sufficiently for the purchaser's purposes, the
matter should be referred to your installing dealer or local distributor.
Manufacturer reserves the right to change specifications or designs without notice.
1/31
Installation Instructions
Inverter Split Heat Pump
Up to 20 SEER
2-3-4-5Ton Capacity
R410A
Contents
1. Safety--------------------------------------------------
3. Position the Unit--------------------------------------
5. Refrigerant Line Routing--------------------------
6. Refrigerant Line Brazing---------------------------
7. System Leak Check---------------------------------
8. Evacuation--------------------------------------------
9. Service Valves---------------------------------------
10. Electrical - Low Voltage----------------------------
11. Electrical - High Voltage---------------------------
12. Start-up------------------------------------------------
13. System Charge Adjustment----------------------
14. System Operation----------------------------------
15. Troubleshooting-----------------------------------------
16. Wiring Diagram----------------------------------------
www.ecoer.com
2
4
6
7
9
10
11
11
12
13
14
15
16
21
28
30
08.2018
