Ahri Data - Johnson Controls RBS009 Engineering Manual

AHRI Data

PSC Motors
AHRI/ASHRAE/ISO 13256-1
English (IP) Units
AHRI 500*
Flow Rate
IEER
Model
EER
gpm cfm
Btuh/W
006 2.0 250 16.7
009 3.0 350 15.3
012 3.0 400 14.7
015 4.0 500 16.0
018 5.0 600 16.3
024 6.0 800 15.7
030 8.0 1000 16.8
036 9.0 1150 17.3
041 11.0 1100 16.1
042 11.0 1400 16.1
048 12.0 1600 16.3
060
15.0 1900 16.4
070 18.0 2100 16.4
Cooling capacities based upon 80.6°F DB, 66.2°F WB entering air temperature
Heating capacities based upon 68°F DB, 59°F WB entering air temperature
All ratings based upon 208V operation
Variable Speed ECM, 5 Speed ECM motor
AHRI/ASHRAE/ISO 13256-1
English (IP) Units
AHRI 500*
Flow Rate
IEER
Model
EER
gpm cfm
Btuh/W Btuh/W
006 2.0 250 17.2
009 3.0 350 16.7
012 3.0 400 15.9
015 4.0 500 16.6
018 5.0 600 17.3
024 6.0 800 16.5
030 8.0 900 17.9
036 9.0 1150 18.1
041 11.0 1300 16.8
042 11.0 1400 17.5
048 12.0 1600 16.8
060 15.0 1900 17.2
070 18.0 2100 17.5
Cooling capacities based upon 80.6°F DB, 66.2°F WB entering air temperature
Heating capacities based upon 68°F DB, 59°F WB entering air temperature
All ratings based upon 208V operation
The purpose of this standard is to establish an IEER and SCHE Method of Calculation for Water/Brine Source Heat Pumps. This standard utilizes
the Published, Certifi ed Data, of performance standard ISO/AHRI/ANSI/ASHRAE 13256-1:1998, and includes the defi nitions; rating requirements;
minimum data requirements for Published Ratings; marking and nameplate data; and conformance conditions required.
Water Loop Heat Pump
Cooling
SCHE
EWT 86°F
COP Capacity EER Capacity
Btuh/W Btuh Btuh/W
16.3 7,100 13.4
16.2 8,100 12.2
15.5 10,200 12.2
16.4 13,200 12.5
16.1 17,300 13.4
16.3 22,900 13.0 26,000
16.7 28,400 13.8 34,000
17.3 34,500 14.0
16.0 37,600 13.5 48,000
16.8 39,200 13.2
16.5 47,200 13.0 59,000
16.2 57,000 13.5 66,000
16.5 66,000 14.0 80,000
Water Loop Heat Pump
Cooling
SCHE
EWT 86°F EWT 68°F
COP Capacity EER Capacity
Btuh Btuh/W Btuh
16.7 7,150 14.0 8,500
17.3 8,300 13.4 11,500
16.3 10,300 13.0 14,500
16.9 13,800 13.2 16,100
17.0 17,300 14.2 19,000
17.0 22,900 13.6 26,000
17.6 28,400 14.7 34,000
18.1 34,500 14.5 43,800
17.1 39,000 13.9 48,500
17.8 39,200 14.2 51,000
17.3 47,200 14.0 59,000
17.1 57,000 14.0 66,000
17.4 66,000 14.6 80,000
Ground Water Heat Pump
Heating Cooling
EWT 68°F EWT 59°F
Capacity EER
COP
Btuh Btuh Btuh/W
8,000 4.3 8,400 21.3
11,400 4.6 9,900 19.2
15,200 4.4 12,200 18.2
15,400 4.5 16,000 20.0
19,000 4.3 19,800 20.5
4.5 27,000 19.8
4.5 33,500 21.0
43,800 4.7 40,000 22.0
4.3 44,500 20.4
51,000 4.7 47,000 20.4
4.6 57,000 19.8
4.3 67,000 21.0
4.5 75,000 20.5
Ground Water Heat Pump
Heating Cooling
EWT 59°F
Capacity EER
COP
Btuh Btuh/W
4.4 8,600 22.0
4.8 10,300 22.0
4.5 12,800 20.0
4.6 16,000 21.0
4.5 19,800 22.0
4.7 27,000 20.8
4.7 33,500 22.5
4.9 40,000 23.0
4.7 45,000 21.0
4.9 47,000 22.0
4.8 57,000 21.0
4.6 67,000 22.0
4.7 75,000 22.0
5
RB SERIES ENGINEERING GUIDE
Ground Loop Heat Pump
Heating Cooling
EWT 50°F EWT 77°F
Capacity Capacity EER
COP
Btuh Btuh Btuh/W
6,800 3.8 7,400 15.5
9,600 4.0 8,900 14.5
12,600 3.9 11,200 14.2
13,000 4.0 14,000 15.3
16,000 3.7 18,000 15.4
22,600 4.0 24,500 14.8
28,000 4.0 30,000 16.0
35,600 4.2 36,000 16.3
38,500 3.8 40,000 15.0
41,400 4.3 42,000 15.2
48,000 4.0 49,500 15.0
55,000 4.0 58,000 15.2
64,000 4.0 68,000 15.6
Ground Loop Heat Pump
Heating Cooling
EWT 50°F EWT 77°F
Capacity Capacity EER
COP
Btuh Btuh Btuh/W
7,100 4.0 7,600 16.0
9,600 4.1 9,100 15.0
11,900 4.0 11,300 15.0
13,400 4.1 14,200 15.7
16,000 3.9 18,000 16.2
22,600 4.2 24,500 15.6
28,000 4.2 30,000 17.0
35,600 4.4 36,000 17.0
38,500 4.1 41,000 16.0
41,400 4.5 42,000 16.6
48,000 4.2 49,500 16.0
55,000 4.2 58,000 16.0
64,000 4.2 68,000 16.6
Heating
EWT 32°F
Capacity
COP
Btuh
5,400 3.2
7,600 3.4
10,200 3.5
10,400 3.2
12,600 3.2
17,000 3.3
21,000 3.3
26,000 3.3
28,500 3.2
30,500 3.3
36,500 3.3
43,000 3.3
49,000 3.3
8/9/18
Heating
EWT 32°F
Capacity
COP
Btuh
5,500 3.2
7,600 3.4
10,200 3.5
11,000 3.3
12,600 3.3
17,000 3.5
21,000 3.5
26,000 3.5
28,500 3.4
30,500 3.5
36,500 3.5
43,000 3.5
49,000 3.5
8/9/18
