11. See the inset drawing. Connect the Upright
Wire (81) to the console wire (G). The connec-
tors should slide together easily and snap
into place. If they do not, turn one connector
and try again. IF YOU DO NOT CONNECT THE
CONNECTORS PROPERLY, THE CONSOLE
MAY BECOME DAMAGED WHEN YOU TURN
ON THE POWER.
Insert the excess wires (G, 81) into the Handrail
(87).
Then, firmly tighten the four 5/16" x 1/2"
Screws (4) (only two are shown).
12. Attach the Right Handrail Cover (92) to the Right
Handrail (87) with three #8 x 1/2" Screws (1); do
not overtighten the Screws.
Attach the Left Handrail Cover (79) to the Left
Handrail (86) in the same way.
11
4
81
G
87
12
79
86
12
G
81
92
1
87
1
