Pro-Form Performance 1500 User Manual
  1. Manuals
  2. Brands
  3. Pro-Form Manuals
  4. Treadmill
  5. 1500 Interactive Trainer
  6. User manual

Pro-Form Performance 1500 User Manual

Hide thumbs Also See for Performance 1500:
Table of Contents

Advertisement

Quick Links

Model No. PETL13015.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
CUSTOMER SERVICE
UNITED KINGDOM
Call: 0330 123 1045
From Ireland: 053 92 36102
Website: www.iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
Unit 1D, The Gateway
Fryers Way, Silkwood Park
OSSETT
WF5 9TJ
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: australiacc@iconfitness.com
Write:
ICON Health & Fitness
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
www.iconeurope.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Performance 1500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pro-Form Performance 1500

Summary of Contents for Pro-Form Performance 1500

  • Page 1 Model No. PETL13015.0 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal CUSTOMER SERVICE UNITED KINGDOM Call: 0330 123 1045 From Ireland: 053 92 36102 Website: www.iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd. Unit 1D, The Gateway Fryers Way, Silkwood Park OSSETT...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 22. Never leave the treadmill unattended while 26. Inspect and properly tighten all parts of the it is running. Always remove the key, press treadmill regularly. the power switch into the off position (see DANGER: the drawing on page 5 for the location of the Always unplug the power power switch), and unplug the power cord cord immediately after use, before clean-...

  • Page 5: Before You Begin

    PERFORMANCE 1500 treadmill. The manual. To help us assist you, please note the product ® PERFORMANCE 1500 treadmill offers an impres- model number and serial number before contacting us. sive selection of features designed to make your The model number and the location of the serial num- workouts at home more effective and enjoyable.

  • Page 6: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 7: Assembly

    ASSEMBLY • Assembly requires two persons. • Left parts are marked “L” or “Left” and right parts are marked “R” or “Right.” • Place all parts in a cleared area and remove the packing materials. Do not dispose of the packing •...
  • Page 8 2. Make sure that the power cord is unplugged. Wire Press a Base Cap (74) into each side of the Base (94). Next, remove the tie securing the Upright Wire (81) to the front of the Base (94). Identify the Right Upright (90). Have a second person hold the Right Upright near the Base (94).
  • Page 9 4. Insert a Wheel Spacer (63) into a Front Wheel (62). Hold the Front Wheel inside the bottom of the Right Upright (90), and insert a 3/8" x 4" Screw (7) with a 3/8" Star Washer (13) into the Right Upright and the Front Wheel. Repeat this step on the left side of the tread- mill (not shown).

  • Page 10: 3/4" Screws (4

    6. Remove and save the four indicated 5/16" x 3/4" Screws (4). Identify the Left and Right Base Covers (82, 83). Slide the Left Base Cover onto the Left Upright (89), and slide the Right Base Cover onto the Right Upright (90). Do not press the Base Covers into place yet.

  • Page 11: 3/4" Screws (4

    8. Insert the Upright Wire (81) into the bottom of the right handrail assembly (D) and out of the front as shown. Attach the right handrail assembly (D) to the Right Upright (90) with two 5/16" x 2 1/2" Screws (28) and two 5/16"...
  • Page 12 10. Identify the Right and Left Trays (27, 36). Attach the Trays (27, 36) to the Console Base (64) with eight #8 x 1/2" Screws (1); do not overtighten the Screws. Reattach the Console Frame (18) with the six #8 x 3/4"...

  • Page 13: 3/4" Screws (4

    12. Hold the console assembly (G) near the Pulse Crossbar (93). Connect the ground wire from the console assembly to the Console Ground Wire (58) on the Pulse Crossbar. Next, set the console assembly (G) on the brack- ets on the Handrails (86); do not pinch any wires.
  • Page 14 15. Insert the Upright Wire (81) and the handrail wire (F) through the two indicated looped ties on the console assembly (G). See the inset drawing. Connect the Upright Wire (81) and the handrail wire (F) to the console wires. The connectors should slide together Ties easily and snap into place.

  • Page 15: 3/4" Screws (4

    17. Firmly tighten the six 3/8" x 4" Screws (7) (only one side is shown). Then, press the Left Base Cover (82) and the Right Base Cover (83) onto the Base (94). 18. Note: If the treadmill is assembled on a smooth surface, it may roll forward during this step.
  • Page 16 19. Remove the 5/16" Nut (12) and the 5/16" x 1 3/4" Bolt (6) from the bracket on the Base (94). Next, orient the Storage Latch (53) as shown. Attach the lower end of the Storage Latch (53) to the bracket on the Base (94) with the 5/16" x 1 3/4"...
  • Page 17 21. Attach the Tablet Holder (88) to the back of the console assembly (G) with four #8 x 1/2" Machine Screws (8); start all four Machine Screws, and then tighten them. Do not over- tighten the Machine Screws. 22. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of plastic on the treadmill decals, remove the plastic.

  • Page 18: How To Use The Treadmill

    HOW TO USE THE TREADMILL HOW TO PLUG IN THE POWER CORD Follow the steps below to plug in the power cord. This product must be earthed. If it should malfunc- 1. Plug the indicated end of the power cord into the tion or break down, earthing provides a path of least socket on the treadmill.
  • Page 19 CONSOLE DIAGRAM FEATURES OF THE CONSOLE You can even listen to your favorite workout music or audio books with the console’s sound system while you The treadmill console offers an impressive array of exercise. features designed to make your workouts more effec- To turn on the power, see page 20.
  • Page 20 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power. If you do See HOW TO TURN ON THE POWER at the left.
  • Page 21 5. Follow your progress with the displays. As you exercise, the workout intensity level bar will indicate the approximate intensity level of your As you walk or run on the treadmill, the display can exercise. show the following workout information: •...
  • Page 22 7. Turn on the fan if desired. 3. Start the workout. The fan features several Press the Run button or the Speed increase button speed settings. Press the to start the workout. A moment after you press the fan buttons repeatedly to button, the treadmill will automatically adjust to the select a fan speed or to first speed and incline settings of the workout.
  • Page 23 HOW TO USE A SET-A-GOAL WORKOUT If the speed or incline setting is too high or too low at any time during the workout, you can manu- ally override the setting by pressing the Speed or 1. Insert the key into the console. Incline buttons;...
  • Page 24 5. Measure your heart rate if desired. 3. Select a user. See step 6 on page 21. If more than one user is registered, you can switch users in the iFit main screen. Press the increase 6. Turn on the fan if desired. and decrease buttons next to the Enter button to select a user.
  • Page 25 5. Start the workout. HOW TO USE THE SOUND SYSTEM See step 3 on page 22. To play music or audio books through the console sound system while you exercise, plug a 3.5 mm male During some workouts, an audio coach may guide to 3.5 mm male audio cable (not included) into the jack you through your workout.
  • Page 26 2. Select the optional screens. 3. Exit the settings mode. While the settings mode is selected, the matrix To exit the settings mode, press the Settings will display several optional screens. Press the button. decrease button next to the Enter button to select each of the following screens: THE OPTIONAL CHEST HEART RATE MONITOR UNITS—To change the unit of measurement, press...

  • Page 27: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left.

  • Page 28: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE SYMPTOM: The power turns off during use Regularly clean the treadmill and keep the walking a. Check the power switch (see drawing c at the left). belt clean and dry. First, press the power switch into If the switch has tripped, wait for five minutes and the off position and unplug the power cord.
  • Page 29 SYMPTOM: The displays of the console do not SYMPTOM: The walking belt slows when walked on function properly a. If an extension cord is needed, use only a 3-conduc- a. Remove the key from the console and UNPLUG tor, 14-gauge (1 mm ) cord that is no longer than 5 THE POWER CORD.
  • Page 30 SYMPTOM: The walking belt is not centered SYMPTOM: The walking belt slips when walked on between the foot rails a. First, remove the key and UNPLUG THE POWER IMPORTANT: If the walking belt rubs against the CORD. Using the hex key, turn both idler roller foot rails, the walking belt may become damaged.

  • Page 31: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
  • Page 32 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch —never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
  • Page 33 NOTES...

  • Page 34: Part List

    PART LIST Model No. PETL13015.0 R0315A Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Screw Reed Switch Clip #8 x 3/4" Screw Reed Switch 5/16" x 2 1/4" Bolt Storage Latch 5/16" x 3/4" Screw Drive Motor #10 Star Washer Motor Belt 5/16"...
  • Page 35 Key No. Qty. Description Key No. Qty. Description #8 x 3/4" Washer Head Screw Receptacle #8 x 3/4" Truss Head Screw Motor Bushing Left Rear Cap #8 x 3/4" Machine Screw Right Rear Cap #8 Nut 1/4" Nut Electronics Bracket Controller Clamp Filter #8 x 1 3/4"...

  • Page 36: Exploded Drawing

    EXPLODED DRAWING A Model No. PETL13015.0 R0315A...
  • Page 37 EXPLODED DRAWING B Model No. PETL13015.0 R0315A...
  • Page 38 EXPLODED DRAWING C Model No. PETL13015.0 R0315A...
  • Page 39 EXPLODED DRAWING D Model No. PETL13015.0 R0315A...

  • Page 40: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
