Model No. PFTL99108.4

Serial No.

Write the serial number in the space

above for reference.

Serial Number Decal

QUESTIONS?

If you have questions, or if parts are

damaged or missing, DO NOT CON-

TACT THE STORE; please contact

Customer Care.

IMPORTANT: Please register this

product (see the limited warranty

on the back cover of this manual)

before contacting Customer Care.

1-888-533-1333

CALL TOLL-FREE:

Mon.–Fri. 6 a.m.–6 p.m. MT

Sat. 8 a.m.–4 p.m. MT

ON THE WEB:

www.proformservice.com

CAUTION

Read all precautions and instruc-

tions in this manual before using

this equipment. Save this manual

for future reference.

All manuals and user guides at all-guides.com

USER'S MANUAL

Table of Contents

Need help?

Do you have a question about the PFTL99108.4 and is the answer not in the manual?

Questions and answers

Summary of Contents for Pro-Form PFTL99108.4

Page 1 All manuals and user guides at all-guides.com www.proform.com USER'S MANUAL Model No. PFTL99108.4 Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, DO NOT CON- TACT THE STORE;...
Page 2: Table Of Contents
All manuals and user guides at all-guides.com TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. .2 IMPORTANT PRECAUTIONS .
Page 3: Important Precautions
All manuals and user guides at all-guides.com IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and in- structions in this manual and all warnings on your treadmill before using your treadmill. ICON as- sumes no responsibility for personal injury or property damage sustained by or through the use of this product.
Page 4 All manuals and user guides at all-guides.com 20. Never leave the treadmill unattended while it 24. Inspect and properly tighten all parts of the is running. Always remove the key, unplug treadmill regularly. DANGER: the power cord, and press the power switch into the off position when the treadmill is not Always unplug the power in use.
Page 5: Before You Begin
All manuals and user guides at all-guides.com BEFORE YOU BEGIN Thank you for selecting the revolutionary PROFORM ing this manual, please see the front cover of this man- ® 1280 PREMIER ES treadmill. The 1280 PREMIER ES ual. To help us assist you, note the product model treadmill offers an impressive selection of features de- number and serial number before contacting us.
Page 6: Assembly
All manuals and user guides at all-guides.com ASSEMBLY To hire an authorized service technician to assemble the treadmill, call 1-800-445-2480. Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant.
Page 7 All manuals and user guides at all-guides.com 2. Identify the Left Upright (73) and the Right Upright (74). See the inset drawing. Tie the wire tie in the Right Upright securely around the end of the Upright Wire (75). With the help of a sec- ond person, hold the Right Upright near the Wire Right Base Cover (77).
Page 8 All manuals and user guides at all-guides.com 4. With the help of a second person, hold the con- sole assembly near the Uprights (73, 74). Console Assembly Connect the Upright Wire (75) to the Console Wire Harness (71). See the inset drawing. The connectors should slide together easily and snap into place.
Page 9 All manuals and user guides at all-guides.com 7. Slide the Right Upright Sleeve (96) up against the console assembly. Attach the Right Upright Sleeve with two #8 x 3/4" Screws (4). Attach the Left Upright Sleeve (not shown) to the console assembly as described above. Console Assembly 8.
Page 10 All manuals and user guides at all-guides.com 10. Locate the chest pulse kit. Hold the Chest Pulse Receiver (53) so the antenna is ori- ented as shown. Attach the Chest Pulse Receiver to the Pulse Receiver Cover (70) with the #3 x 1/4" Screw (84) included in the chest pulse kit.
Page 11: Operation And Adjustment
All manuals and user guides at all-guides.com OPERATION AND ADJUSTMENT THE PRE-LUBRICATED WALKING BELT that is properly installed and grounded in accor- dance with all local codes and ordinances. IMPORTANT: The treadmill is not compatible with Your treadmill features a walking belt coated with high- performance lubricant.
Page 12: Console Diagram
All manuals and user guides at all-guides.com CONSOLE DIAGRAM Clip FEATURES OF THE CONSOLE trol the treadmill. iFit cards are available separately. To purchase iFit cards at any time, go to www.iFit.com or call the telephone number on the front cover of The treadmill console offers an impressive array of this manual.
Page 13 All manuals and user guides at all-guides.com HOW TO TURN ON THE POWER Follow the steps below to personalize the console settings. IMPORTANT: If the treadmill has been exposed to cold temperatures, allow it to warm to room tem- To select the settings mode, first remove the key from perature before turning on the power.
Page 14: How To Use The Manual Mode
All manuals and user guides at all-guides.com HOW TO USE THE MANUAL MODE Speed increase button, or one of the numbered speed buttons. 1. Insert the key into the console. 5. Change the incline of the treadmill as desired. See HOW TO TURN ON THE POWER on page 13.
Page 15 All manuals and user guides at all-guides.com • In addition, the display can show a “workout his- Before using tory”—a profile that represents the speed set- the handgrip tings that you select during your workout. At the pulse sensor, beginning of each minute of your workout, an remove the additional column will appear in the profile;...
Page 16 All manuals and user guides at all-guides.com HOW TO USE A PRESET WORKOUT At the end of the first one-minute segment of the workout, a series of tones will sound. If a different 1. Insert the key into the console. speed and/or incline setting is programmed for the second segment, the speed setting and/or incline See HOW TO TURN ON THE POWER on page...
Page 17 All manuals and user guides at all-guides.com HOW TO CREATE A CUSTOM WORKOUT To program a speed setting and an incline setting for the first one-minute segment of the workout, 1. Insert the key into the console. simply adjust the speed and incline of the treadmill as desired by pressing the Speed and Incline but- See HOW TO TURN ON THE POWER on page tons.
Page 18 All manuals and user guides at all-guides.com HOW TO USE A CUSTOM WORKOUT A profile of the speed 1. Insert the key into the console. settings of the work- See HOW TO TURN ON THE POWER on page out will ap- pear in the display.
Page 19 All manuals and user guides at all-guides.com HOW TO USE THE SOUND SYSTEM To stop the workout at any time, press the Stop button. To restart the workout, press the Start but- ton. The walking belt will begin to move at 1 mph. To play music or audio books through the consoleʼs When the next segment of the workout begins, the sound system, you must connect your MP3 player, CD...
Page 20 All manuals and user guides at all-guides.com HOW TO USE AN IFIT CARD Note: The same speed and/or incline setting may be programmed for consecutive segments. To purchase iFit cards at any time, go to www.iFit.com 4. Start the walking belt. or call the telephone number on the front cover of this manual.
Page 21: How To Fold And Move The Treadmill
All manuals and user guides at all-guides.com HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to the lowest position before you fold the treadmill.
Page 22: Troubleshooting
All manuals and user guides at all-guides.com TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a.
Page 23 All manuals and user guides at all-guides.com Lower the treadmill (see HOW TO LOWER THE TREADMILL FOR USE on page 21). Then, remove the four indicated #8 x 3/4" Screws (4), and remove the Motor Hood (44). Next, locate the Reed Switch (20) and the Magnet (12) on the left side of the Pulley (11).
Page 24 All manuals and user guides at all-guides.com PROBLEM: The walking belt is off-center or slips when walked on SOLUTION: a. If the walking belt is off-center, remove the key and UNPLUG THE POWER CORD. If the walking belt has shifted to the left, use the hex key to turn the left idler roller bolt clockwise 1/2 of a turn;...
Page 25: Exercise Guidelines
All manuals and user guides at all-guides.com EXERCISE GUIDELINES WARNING: Burning Fat—To burn fat effectively, you must exer- cise at a low intensity level for a sustained period of Before beginning any time. During the first few minutes of exercise, your exercise program, consult your physician.
Page 26: Part List
All manuals and user guides at all-guides.com PART LIST—Model No. PFTL99108.4 R0610A To locate the parts listed below, see the EXPLODED DRAWING near the end of this manual. Key No. Qty. Description Key No. Qty. Description Foot Rail Cover Right Rear Foot...
Page 27 All manuals and user guides at all-guides.com Key No. Qty. Description Key No. Qty. Description Latch Warning Decal Stop Bracket Spacer #8 x Tek 3/4" Screw #8 x 1/2" Console Ground Screw #8 x 1" Screw Console Plate Speaker Cover Handrail Cap #10 Washer –...
Page 28: Exploded Drawing
All manuals and user guides at all-guides.com EXPLODED DRAWING A—Model No. PFTL99108.4 R0610A...
Page 29 All manuals and user guides at all-guides.com EXPLODED DRAWING B—Model No. PFTL99108.4 R0610A...
Page 30 All manuals and user guides at all-guides.com EXPLODED DRAWING C—Model No. PFTL99108.4 R0610A...
Page 31 All manuals and user guides at all-guides.com EXPLODED DRAWING D—Model No. PFTL99108.4 R0610A...
Page 32: Ordering Replacement Parts
All manuals and user guides at all-guides.com ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
