Model No. PETL10714.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
CUSTOMER SERVICE
UNITED KINGDOM
Call: 08457 089 009
From Ireland: 053 92 36102
Website: www.iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
c/o HI Group PLC
Express Way
CASTLEFORD
WF10 5QJ
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: australiacc@iconfitness.com
Write:
ICON Health & Fitness
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
www.iconeurope.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Performance 1050 PETL10714.0 and is the answer not in the manual?

Questions and answers

Related Manuals for Pro-Form Performance 1050 PETL10714.0

Summary of Contents for Pro-Form Performance 1050 PETL10714.0

  • Page 1 Model No. PETL10714.0 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal CUSTOMER SERVICE UNITED KINGDOM Call: 08457 089 009 From Ireland: 053 92 36102 Website: www.iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd. c/o HI Group PLC Express Way CASTLEFORD...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 DANGER: 21. Do not attempt to move the treadmill until it Always unplug the power is properly assembled. (See ASSEMBLY on cord immediately after use, before clean- page 7 and HOW TO FOLD AND MOVE ing the treadmill, and before performing the THE TREADMILL on page 25.) You must be maintenance and adjustment procedures able to safely lift 45 lbs.

  • Page 5: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the new PROFORM reading this manual, please see the front cover of this ® PERFORMANCE 1050 treadmill. The manual. To help us assist you, note the product model PERFORMANCE 1050 treadmill provides an impres- number and serial number before contacting us.

  • Page 6: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 7: Assembly

    ASSEMBLY • Assembly requires two persons. • Left parts are marked “L” or “Left” and right parts are marked “R” or “Right.” • Place all parts in a cleared area and remove the packing materials. Do not dispose of the packing •...
  • Page 8 2. Make sure that the power cord is unplugged. Wire Press a Base Cap (74) into each side of the Base (85). Identify the Right Upright (90). Have a second person hold the Right Upright near the Base (85). See the inset drawing. Tie the wire tie in the Right Upright (90) securely around the end of the Wire Upright Wire (81).
  • Page 9 4. Hold the Right Upright (90) against the Base (85). Be careful not to pinch the wires. Partially tighten three 3/8" x 4" Screws (7) with three 3/8" Star Washers (13) into the Right Upright and the Base; do not fully tighten the Screws yet.

  • Page 10: Make Sure That The Upright Wire (81) Is Not

    6 . Set a Handrail (84) onto the Right Upright (90). Make sure that the Upright Wire (81) is not pinched. Attach the Handrail (84) with two 5/16" x 2 1/4" Screws (28) and two 5/16" Star Washers (11). Start both Screws, and then tighten them. Attach the other Handrail (not shown) in the same way.
  • Page 11 8. With the help of a second person, hold the con- sole assembly near the right Handrail (84) and Console the left Handrail (not shown). Assembly See the inset drawing. Connect the Upright Wire (81) to the console wire. The connectors should slide together easily and snap into place.
  • Page 12 10. IMPORTANT: To avoid damaging the Pulse Crossbar (5), do not use power tools and do not overtighten the #10 x 3/4" Screws (9). Tighten four #10 x 3/4" Screws (9) with four 1/4" Star Washers (26) into the Pulse Crossbar (5) and the Handrails (84).
  • Page 13 12. Identify the Left and Right Handrail Covers (87, Console Slide the Left Handrail Cover (87) up against the Assembly console assembly and tighten a #8 x 3/4" Screw (4) into the bottom of the Left Handrail Cover. Be careful not to overtighten the Screw. Attach the Right Handrail Cover (8) in the same way.
  • Page 14 14. Orient the Storage Latch (96) so that the decals are facing away from the treadmill as shown. Attach the lower end of the Storage Latch (96) to the bracket on the Base (85) with a 5/16" x 1 3/4" Bolt (94), two Latch Spacers (98), and a 5/16"...
  • Page 15 16. Firmly tighten all six 3/8" x 4" Screws (7). Then, slide the Left and Right Base Covers (82, 83) downward. 17. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of plastic on the treadmill decals, remove the plastic.

  • Page 16: The Chest Heart Rate Monitor

    THE CHEST HEART RATE MONITOR HOW TO PUT ON THE HEART RATE MONITOR • Do not expose the heart rate monitor to direct sun- light for extended periods of time; do not expose it to The heart rate temperatures above 122° F (50° C) or below 14° F monitor consists of (-10°...

  • Page 17: How To Use The Treadmill

    HOW TO USE THE TREADMILL HOW TO PLUG IN THE POWER CORD Follow the steps below to plug in the power cord. This product must be earthed. If it should malfunc- 1. Plug the indicated end of the power cord into the tion or break down, earthing provides a path of least socket on the treadmill.
  • Page 18 CONSOLE DIAGRAM FEATURES OF THE CONSOLE You can even listen to your favorite workout music or audio books with the console’s stereo sound system The treadmill console offers an impressive array of while you exercise. features designed to make your workouts more effec- To turn on the power, see page 19.
  • Page 19 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power. If you do See HOW TO TURN ON THE POWER at the left.
  • Page 20 5. Follow your progress with the displays. 6. Measure your heart rate if desired. The matrix—When Note: If you use the handgrip heart rate moni- tor and the chest heart rate monitor at the same you select the manual time, the console will not display your heart mode, the matrix will display a track that rate accurately.

  • Page 21: How To Use Onboard Workout

    HOW TO USE AN ONBOARD WORKOUT The workout will continue in this way until the last segment of the profile flashes in the display and the 1. Insert the key into the console. last segment ends. The walking belt will then slow to a stop.
  • Page 22 HOW TO USE AN IFIT WORKOUT When you select an iFit workout, the display will show the name, duration, maximum speed setting, Note: To use an iFit workout, you must have an and distance of the workout. The display will also optional iFit module.
  • Page 23 HOW TO USE THE SOUND SYSTEM THE INFORMATION MODE To play music or audio books through the console The console features an information mode that keeps sound system while you exercise, plug a 3.5 mm male track of treadmill information and allows you to person- to 3.5 mm male audio cable (not included) into the jack alize console settings.
  • Page 24 MODULE—If an iFit module is connected, the the network SSID, the network encryption type, display will show the word WIFI. If a USB module is the wireless signal strength, the IP address of connected, the display will show the word USB/SD. the module, the number of registered users and their names, and the results of the DNS lookup.

  • Page 25: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left.

  • Page 26: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE SYMPTOM: The console displays remain lit when you remove the key from the console Regularly clean the treadmill and keep the walking belt clean and dry. First, press the power switch into a. The console features a display demo mode, the off position and unplug the power cord.
  • Page 27 Next, locate the Reed Switch (52) and the Magnet b. If the walking belt is overtightened, treadmill per- (50) on the left side of the Pulley (49). Turn the formance may decrease and the walking belt may Pulley until the Magnet is aligned with the Reed become damaged.
  • Page 28 SYMPTOM: The walking belt is not centered SYMPTOM: The walking belt slips when walked on between the foot rails a. First, remove the key and UNPLUG THE POWER IMPORTANT: If the walking belt rubs against the CORD. Using the hex key, turn both idler roller foot rails, the walking belt may become damaged.

  • Page 29: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 30: Part List

    PART LIST Model No. PETL10714.0 R0114A Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Screw Cable Tie 1/4" x 1/2" Screw Drive Roller/Pulley Base Pad Magnet #8 x 3/4" Screw Reed Switch Clip Pulse Crossbar Reed Switch Filter 1/4"...
  • Page 31 Key No. Qty. Description Key No. Qty. Description 5/16" x 2 1/4" Shoulder Bolt Latch Spacer Storage Latch Base Pad Spacer Latch Crossbar – User’s Manual Note: Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of this manual.

  • Page 32: Exploded Drawing

    EXPLODED DRAWING A Model No. PETL10714.0 R0114A...
  • Page 33 EXPLODED DRAWING B Model No. PETL10714.0 R0114A...
  • Page 34 EXPLODED DRAWING C Model No. PETL10714.0 R0114A...
  • Page 35 EXPLODED DRAWING D Model No. PETL10714.0 R0114A...

  • Page 36: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
