3.38 Data Matrix

<Default All Matrix 2 of 5 Settings>
* On
3.38.1

Data Matrix Message Length

Scan the bar codes below to change the message length. Refer to Message Length Description
(chapt 3.2) for additional information. Minimum and Maximum lengths = 1-1500. Minimum Default =
1, Maximum Default = 1500.
Minimum Message Length

3.39 MaxiCode

< Default All MaxiCode Settings >
3.39.1

MaxiCode Message Length

Scan the bar codes below to change the message length. Refer to Message Length Description
(chapt 3.2) for additional information. Minimum and Maximum lengths = 1-150. Minimum Default = 1,
Maximum Default = 150.
Off

Maximum Message Length

Maximum Message Length
40
