Mirage SoftGel
™
NASAL MASK
Fitting Guide
1
• Turn the MicroFit dial to position • Disconnect the lower headgear clip,
24, so that the forehead support hold the mask over the nose and pull
is fully extended. the headgear over the head.
4
• Adjust the upper straps evenly. • Adjust the lower straps to a
Do not over-tighten. comfortable position.
7
T
I
P
• Adjust dial to correct leak at nose. • Adjust bottom straps to correct leak
at top lip.
ResMed Corp San Diego, CA, USA +1 858 836 5000 or 1 800 424 0737 (toll free). ResMed Ltd Bella Vista, NSW, Australia +61 (2) 8884 1000 or 1 800 658 189 (toll free). See www.resmed.com for other ResMed locations
worldwide. ConvertAble and DoubleGel are trademarks of ResMed Ltd. Mirage is a trademark of ResMed Ltd and registered in the U.S. Patent and Trademark Office. ©2009 ResMed Ltd. Specifications may
change without notice. 1013468/1 09 08
Global leaders in sleep and respiratory medicine
2 3
• Reconnect the lower headgear clip,
ensuring it clicks into place.
5 6
• Connect one end of the air tubing to
the swivel and the other end to the
airflow device.
• Turn on the airflow device.
T
I
P
www.resmed.com
Mirage SoftGel
™
NASAL MASK
ConvertAble ™ Comfort
The Mirage ™ SoftGel Nasal Mask offers exceptional comfort
with ResMed's renowned performance and quality.
Easy and quick to fit, Mirage SoftGel is part of ResMed's
exclusive ConvertAble ™ Series, giving you the choice of two
MicroFit dial
offers 24 positions for better fit,
seal and comfort
ResMed ConvertAble frame
accommodates both Mirage SoftGel
and Mirage Activa ™ LT cushions for
business efficiency, cost savings and flexibility
360° elbow rotation
positions the tubing for
maximum comfort
Quiet, diffused vent design
disperses air softly and quietly,
away from bed partner
Elbow partition
aids CO washout and reduces noise output
2
mask cushions on one durable frame. Featuring a soft touch
with excellent support, Mirage SoftGel adds the comfort,
durability and freedom of choice that only a ConvertAble mask
can offer.
SoftGel's unique DoubleGel ™ cushion
Clear gel layer provides ultimate
comfort; blue gel layer provides
support and stability
Set-and-forget headgear clips
retain optimal headgear settings;
easy to attach and detach
Swivel
offers a convenient way to
connect and disconnect
air tubing
