WOODSTOCK Ottoman
King Bed
Assembly Instructions
Before you
Start, here
are some
helpful
advices.
1. We suggest you spend a short time reading through this leaflet and then
follow the simple step by step instructions.
2. If you follow the instructions carefully the end result should be worth the
effort.
3. Do not discard any of the packaging until you have checked that you
have all the parts and the pack of fittings.
4. Assemble this product on a carpet.
5. To ensure an easier assembly, we strongly advise that all fittings are only
finger tightened during initial assembly. Only upon completion of the.
Assembly should all fixing points be fully tightened.
6. We recommend a periodic check on all fixing points to make sure they
remain fully tightened.
7. Keep glue and fittings out of children's reach.
In the unlikely event that this product has missing or damaged parts, please
call 03442 920000 to obtain spares
spare
1of 8
Page
Advertisement
Related Manuals for DREAMS WOODSTOCK Ottoman King Bed
Summary of Contents for DREAMS WOODSTOCK Ottoman King Bed
- Page 1 WOODSTOCK Ottoman King Bed Assembly Instructions Before you 1. We suggest you spend a short time reading through this leaflet and then follow the simple step by step instructions. Start, here 2. If you follow the instructions carefully the end result should be worth the are some effort.
- Page 2 PARTS Fittings Philips headbots M8×50mmx8pcs Allen bolts M8×80mmx2pcs M4 Allen key × 1pc GLIDES x 2psc NO. PART LIST (1) HEADBOARD (2) FOOTBOARD 11Spanner × 1pc (3) SIDE RAILS ( Right ) (4) SIDE RAILS ( Left ) Flat Washer M8 x10pcs (5) CROSS BAR (6) OUTER BAR HEX NUT M8 x10pcs...
- Page 3 ASSEMBLY STEP 1 (1) Use bolt (mounted on the headboard and footboard) to fix the side rail (3) onto Headboard (1) and Footboard (2) by using Allen Key (C). (2) Place the assembled Bed frame in the desire location of the room (3) Fully tight all bolts 100% using allen key (C) , Make sure...
- Page 4 ASSEMBLY STEP 2 Secure adjustable glides (K) to the cross bar (5) by screwing the glides (2) Place the cross bar (5) to the side rails (3) (4) (3) Place the 2 outer bar (6) inner illustrated . Page 4 of 8...
- Page 5 ASSEMBLY STEP 3 (1).Place the bottom board (8) and (9) as illustrated . Page 5 of 8...
- Page 6 ASSEMBLY STEP 4 (1).Secure the gas spring to the metal lift hinges in place , at both side rails . (2).Tighten nuts with spanner (E) do not over tighten. A small gap is left so stems can move freely- this is important-see sketch.
- Page 7 ASSEMBLY STEP 5 (1).Secure the metal slats assembly (10) middle Joint with Allen bots (B), flat washer (F) and Hex nut ( G ) using allen key (C) and Spanner (E) (2).Place and secure the Metal Mattress stoper (11) to the Metal Slats assembly (10) with Hex nut ( I ) using Spanner (E).
- Page 8 ASSEMBLY STEP 6 (1).Place and secure the metal slats assembly with Philip head bolt (A) , Flats washer (F) and Hex nut (G) using spanner (E) . NOTE : WHEN FULLY ASSEMBLY AND THE MATRESS POSITION, PLEASE RAISE AND LOWER THE OTTOMAN 4-5 TIMES , TO ENSURE THE GAS PISTON ARE FULLY LUBRICATED .
