Woodstock – Double Bed / King Bed
Assembly Instructions
Before you
Start, here
are some
helpful
advices.
1. We suggest you spend a short time reading through this leaflet and then follow
the simple step by step instructions.
2. If you follow the instructions carefully the end result should be worth the effort.
3. Do not discard any of the packaging until you have checked that you have all
the parts and the pack of fittings.
4. Assemble this product on a carpet.
5. To ensure an easier assembly, we strongly advise that all fittings are only
finger tightened during initial assembly. Only upon completion of the assembly
should all fixing points be fully tightened.
6. We recommend a periodic check on all fixing points to make sure they remain
fully tightened.
7. Keep glue and fittings out of children's reach.
the unlikely event that this product has missing or damaged parts, please call
0344 292 0000 to obtain spares
spare
Page 1 of 5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WOODSTOCK and is the answer not in the manual?

Questions and answers

Summary of Contents for DREAMS WOODSTOCK

  • Page 1 Woodstock – Double Bed / King Bed Assembly Instructions Before you 1. We suggest you spend a short time reading through this leaflet and then follow the simple step by step instructions. Start, here 2. If you follow the instructions carefully the end result should be worth the effort.
  • Page 2 PARTS Fittings M6×45mm x 6pcs M6 × 6pcs Allen Key M4 x 2pcs Metal washer x 6pcs Screw 35mm x 1pc NO. PART LIST (1) Headboard (2) Footboard (3) Side Rails (4) Support Leg Page 2 of 5...
  • Page 3 ASSEMBLY STEP1 - Use bolt (mounted on the headboard and footboard) to fix the side rail (3) onto headboard (1) and footboard (2) by using Allen Key (C). Page 3 of 5...
  • Page 4 Both slats on "step 2" and "step 3" can be assembled to the bedstead. You can make a choice between the two slats. OPTION"A": DREAMS FIXED WOOD SLATS (1) Carefully locate the slats onto the unit, as step 2: Use bolt (A), washer (D) and...
  • Page 5 ASSEMBLY STEP 3 OPTION"B": DREAMS SPRUNG SLATS (1) Use the bolt to fix support leg onto the slat frame. Please note that these bolts are to be found inside the slat frame box. (2) Carefully locate the slats onto the unit.
