- Page 1 Murphy Ottoman Bed 1.5 hour approx Two person assembly time assembly MK2 201123...
- Page 2 Thank you Hello, thanks for choosing to purchase your bed from Dreams - you're now on your way to your best ever night's sleep. Before you begin building your bed, please take a moment to read through the instructions and make sure that you've got all the relevant parts listed on the following pages.
- Page 3 Side rail - Right Bedsides Slat Frame Support Rail Metal Legs for Bedsides Angle Brackets Power adapter with 90º LV plug Storage Base Boards Tools required Tape measure Cross head screwdriver Murphy Ottoman Bed - Assembly guide - Page 3...
- Page 4 Bolts (M8x45mm) for fitting metal slat frame (H) to gas-lift mechanisms & Flange lock-nuts (M8) fitting slat frame support rail Metal Connection Plates for gas-lift pistons (E) to footboard (B) 0 10 1 Murphy Ottoman Bed - Assembly guide - Page 4...
- Page 5 (y) making certain both red cables are on same side of both the plug & the socket as shown below. c) Re-zip compartments and headboard assembly is now complete. Murphy Ottoman Bed - Assembly guide - Page 5...
- Page 6 Screw the threaded bolts (f) into the tapped holes in rear of the bedside chests until they stop, do not over- tighten.. Murphy Ottoman Bed - Assembly guide - Page 6...
- Page 7 Bed assembly - use pack 'D' 10mm 10mm Murphy Ottoman Bed - Assembly guide - Page 7...
- Page 8 Lift the Headboard into final position. Please do not drag it across the floor or the legs on the bedsides may be damaged. Also make certain the power cable is not trapped. & & Murphy Ottoman Bed - Assembly guide - Page 8...
- Page 9 Metal slat frame assembly use pack 'E' & Make certain the bed is squared up 100% as shown in the diagram then tighten all bed assembly bolts 100%. Murphy Ottoman Bed - Assembly guide - Page 9...
- Page 10 Align with the threaded holes and loosely fix through the plates using bolts (i), spring washers (b) & flat washers (c). Using Allen key (d), now tighten all six bolts 100%. Murphy Ottoman Bed - Assembly guide - Page 10...
- Page 11 Using three bolt sets on each side (b), (c), (e) & (l), fix slat frame to the support bars but do not tighten fully yet. & Bolt into centre of long holes Murphy Ottoman Bed - Assembly guide - Page 11...
- Page 12 Tighten nuts with spanner (h) - but do not over-tighten. A small gap is needed so stems can move freely - this is important - see sketch below. & SMALL GAP Murphy Ottoman Bed - Assembly guide - Page 12...
- Page 13 Always use the strap to lift or lower the frame - keep fingers well away from the moving parts. When fully assembled and the mattress in position, please raise & lower the ottoman 4/5 times to ensure the gas pistons are fully lubricated. Murphy Ottoman Bed - Assembly guide - Page 13...
- Page 14 Metal tends to be more resilient to everyday wear and tear. We recommend to gently dust your metal furniture and keep it dry to maintain its look. Thank you for shopping with us - we hope you have a great night's sleep Care and maintenance guide Murphy Ottoman Bed - - Page 14...
