- Page 1 Ullswater / Tollymore Bed Double, King & Super King Assembly Instructions OPTION 1: OPTION 2: OPTION 3: SOLID SLATS SPRUNG SLATS SLEEPMOTION 1/2 hour approx assembly time...
- Page 2 Ullswater/Tollymore Bed...
- Page 3 Ullswater /Tollymore Be d...
- Page 4 Ullswater/Tollymore...
- Page 5 STEP1 - Use bolt (mou nted on the headboard and footboard ) to fix the Side Rail (3 onto Headboard 1 and Footboard (2) by usin g Allen Key (C). Ullswater / Tollymore Bed - Assembly Guide - Page 5...
- Page 6 JCN nut (B ) to fix the unit using Allen Key (C) (2) Fit the adjustable S upport Leg (4) to the center slat. Secure with Screw (E) using Screwdriver (not t included provided). Ullswater / Tollymore Bed - Assembly Guide - Page 6...
- Page 7 (2) Carefully locate the slats onto the unit. (3) Use bolt (A) and JCN nut (B) to fix the unit using Allen Key (C). Ullswater / Tollymore Bed - Assembly Guide - Page 7...
- Page 8 Sleepmotion attach the Side Rail (3) using bolt mounted on the headboard with Allen Key (C) - place the assembled parts 10mm from the corner of Sleepmotion as illustrated. Ullswater / Tollymore Bed - Assembly Guide - Page 8...
- Page 9 ASSEMBLY SLEEPMOTION OPTION STEP 2 -Raise the Head end and foot end of the Sleepmotion using the supplied remote control Ullswater / Tollymore Bed - Assembly Guide - Page 9...
- Page 10 ASSEMBLY SLEEPMOTION OPTION STEP 3 Position the Footboard (2) to assemble with the Side Rail (3) using the bolt mounted in the Foot board with Allen Key(C) Ullswater / Tollymore Bed - Assembly Guide - Page 10...
- Page 11 STEP 4 Make sure everything is working properly then fit second side rail Attach the other s ide rail (3) to Headboard (1) and Footboard (2) using Allen Key (C). Ullswater / Tollymore Bed - Assembly Guide - Page 11...
- Page 12 ASSEMBLY SLEEPMOTION OPTION STEP 5 MAKE SURE THAT THE BED IS SQUARE UP AS SHOWN ON THE RIGHT. FULLY TIGHTEN ALL BOLTS using Allen Key (C). Ullswater /Tollymore Bed - Assembly Guide - Page 12...
- Page 13 ASSEMBLY SLEEPMOTION OPTION Make Certain Gaps STEP around the Bed Base are correct. Ullswater / Tollymore Bed - Assembly Guide - Page 13...
- Page 14 Ullswater /Tollymore Bed...
