Installation and Operation Manual
TecJet™ 110 Gas Regulation
and Metering Valve / Actuator System
Manual 26185 (Revision F)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TecJet 110 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Woodward TecJet 110

Summary of Contents for Woodward TecJet 110

  • Page 1 Installation and Operation Manual TecJet™ 110 Gas Regulation and Metering Valve / Actuator System Manual 26185 (Revision F)
  • Page 2 Revisions—Text changes are indicated by a black line alongside the text. Woodward Governor Company reserves the right to update any portion of this publication at any time. Information provided by Woodward Governor Company is believed to be correct and reliable. However, no responsibility is assumed by Woodward Governor Company unless otherwise expressly undertaken.

  • Page 3: Table Of Contents

    LECTROSTATIC ISCHARGE WARENESS 1. G ............1  HAPTER ENERAL NFORMATION Introduction ......................1   Connections to the TecJet 110 ................1   2. I ................2  HAPTER NSTALLATION Introduction ......................2   Mounting ......................... 2   Electrical Connections .................... 4  ...
  • Page 4   Figure 3-1. Address Claimed State Chart ............20   Figure 4-1. Maximum and Minimum Specialty Gas Flow Capacity of TecJet 110, 50 Plus, and 50 ................26   Figure 4-2. Maximum and Minimum Natural Gas Flow Capacity of TecJet 110, 50 Plus, and 50 ................

  • Page 5: Regulatory Compliance

    Division 2, or Zone 2 wiring methods as applicable, and in accordance with the authority having jurisdiction. Wiring for the TecJet 110 power input must be suitable for at least 85 °C. Connect ground lug of TecJet 110 to earth ground.

  • Page 6: Electrostatic Discharge Awareness

    PCB from the control cabinet, place it in the antistatic protective bag. To prevent damage to electronic components caused by improper handling, read and observe the precautions in Woodward manual 82715, Guide for Handling and Protection of Electronic Controls, Printed Circuit Boards, and Modules.

  • Page 7: Chapter 1. General Information

    Throughout the remainder of the manual, the TecJet 110 valve and actuator system will be referred to simply as the TecJet 110. Connections to the TecJet 110 The TecJet 110 valve has the following connections to the ECM (Engine Control Module), and the engine harness: Earth Ground Provided through ground lug on housing.

  • Page 8: Chapter 2. Installation

    Give consideration to the strength of the mounting plate in order to support the 31 kg (68 lb) weight of the TecJet 110. Refer to the outline drawing in Figure 2-1 for dimensions and details relative to the valve inlet flange and outlet flange.

  • Page 9: Figure 2-1. Tecjet 110 Outline Drawing

    Manual 26185 TecJet 110 Fuel Metering System Figure 2-1. TecJet 110 Outline Drawing Woodward...

  • Page 10: Electrical Connections

    TecJet 110 Fuel Metering System Manual 26185 The inlet and outlet piping of the TecJet 110 must be in accordance with ANSI/ISA-S75.02 to ensure the flow metering accuracy specified elsewhere in this manual. However, an inlet piping length as short as 6 diameters and an outlet piping length as short as 2 diameters can typically be used with a negligible loss in valve metering accuracy.

  • Page 11: Figure 2-2. Tecjet 110 Valve Wiring Diagram

    Contact Woodward for more information. Failure to provide shielding can produce future conditions which are difficult to diagnose. Proper shielding at the time of installation is required to ensure satisfactory operation of the TecJet 110 Gas Metering System. From Previous CAN Device...

  • Page 12: Earth Ground

    The keyswitch is not active in all TecJet configurations. The keyswitch is used to switch the TecJet 110 in and out of a low power state (less than 200 mA input current). A high signal (connected to supply [+]) will allow the valve to operate in a normal mode, and a low signal (connected to supply [–] or open connection)

  • Page 13: Pwm Input

    TecJet 110 is used on an engine. If one TecJet 110 valve is replaced with another, the new valve will read the correct ID number from the engine harness connector. See the table below for the code definition.

  • Page 14: Can Termination

    According to the CAN specification, every CANbus must be terminated at both ends of the bus. If a TecJet 110 valve is connected to the far end of the bus, this termination resistor can be used. If termination is needed, connect a link between pins P and Q.

  • Page 15: Can Shield

    E = Status Output J = Discrete/RS232 Common The status output indicates whether the TecJet 110 valve is operating correctly. It will be "on" when the valve is operating normally and "off" when any warnings or errors are active. The Status Output is a high-side switch: it will be actively driven to Battery (+) when "on"...

  • Page 16: Chapter 3. Description Of Operation

    CAN link. If a problem is detected, the valve will not operate and the status output will indicate a fault. The TecJet 110 is typically continuously connected to the supply voltage. If the flow demand source is configured to Jenbacher CAN, the key switch has no effect.

  • Page 17: Diagnostics

    Manual 26185 TecJet 110 Fuel Metering System Diagnostics The TecJet 110 may not return to minimum fuel for all faults. The engine, turbine, or other type of prime mover should be equipped with an overspeed, misfire, detonation detection shutdown device(s),...

  • Page 18: Position Limiter

    Manual 26185 Position Limiter After the TecJet 110 is powered up and receives a flow command, the valve remains in a closed position until the delta-p sensor senses a non-zero valve delta-p. This non-zero delta-p is established when the fuel source is turned on.
  • Page 19 Manual 26185 TecJet 110 Fuel Metering System TecJet PDO Support All data in CANopen is formatted as “Little Endian” also known as “Intel Format”. This section lists the PDOs that will be sent from the TecJet. The TecJet will use the standard connection set to assign PDO numbers. The Node ID determines the COB ID for the PDOs.
  • Page 20 TecJet 110 Fuel Metering System Manual 26185 Transmit PDO 2 - Gaseous Fuel Flow Transmission rate: 99ms Message type = “ASYNC” (does not require SYNC message) COB Id: 658 (0x292) default for Node Id = 18. All others 640+Node Id.
  • Page 21 Manual 26185 TecJet 110 Fuel Metering System Byte 5 Bit 0: BATTERY_VOLT_LOW_ERR Bit 1: FGT_LOW_LIMIT_ERR Bit 2: DELTA_P_LOW_LIMIT_ERR Bit 3: FGP_LOW_LIMIT_ERR Bit 4: BATTERY_VOLT_HIGH_ERR Bit 5: FGT_HIGH_LIMIT_ERR Bit 6: DELTA_P_HIGH_LIMIT_ERR Bit 7: FGP_HIGH_LIMIT_ERR Byte 6 Bit 0: RESERVED Bit 1: WATCHDOG_RESET...

  • Page 22: Sae J1939 Communications

    Byte 8 BYTE SAE J1939 Communications The TecJet 110, 50 Plus, and Precision Flow devices support CAN communications in the SAE J1939 Higher Layer Protocol format. Further detailed information regarding the J1939 Standards Collection can be purchased at www.sae.org. Information about CAN is at www.semiconductors.bosch.de.
  • Page 23 Manual 26185 TecJet 110 Fuel Metering System Gaseous Fuel Command Transmission rep rate: 5 ms (Engine Control TecJet 50 Plus) Data length: 8 bytes Data page: PDU format: Note that this is the only Proprietary PDU Format 1 message allowed in J1939.
  • Page 24 TecJet 110 Fuel Metering System Manual 26185 Gaseous Fuel Flow Transmission repetition rate: 100 ms (TecJet 50 Plus Engine Control) Data length: 8 bytes Data Page: PDU format: PDU specific: Default priority: Parameter Group Number: 65534 (0xFFFE) Data: Bytes 1-4: Fuel Flow...
  • Page 25 Manual 26185 TecJet 110 Fuel Metering System Byte 5 Bit 0: BATTERY_VOLT_LOW_ERR Bit 1: FGT_LOW_LIMIT_ERR Bit 2: DELTA_P_LOW_LIMIT_ERR Bit 3: FGP_LOW_LIMIT_ERR Bit 4: BATTERY_VOLT_HIGH_ERR Bit 5: FGT_HIGH_LIMIT_ERR Bit 6: DELTA_P_HIGH_LIMIT_ERR Bit 7: FGP_HIGH_LIMIT_ERR Byte 6 Bit 0: RESERVED Bit 1: WATCHDOG_RESET...

  • Page 26: Figure 3-1. Address Claimed State Chart

    TecJet 110 Fuel Metering System Manual 26185 Start executing Power On Self Test POST Complete- Send Address Claim Random Delay before sending Address Delay Complete- Claimed Send Address Claim “Bus-off Error occurred or collision detected Check for Message Received a contending...

  • Page 27: Position Hold Feature

    The TecJet 110, 50 Plus, and Precision Flow devices have a position hold feature for use in analyzing or troubleshooting engine system operation. This allows qualified operators to bypass the normal flow control function and specify a fixed valve position.

  • Page 28: General Specifications

    TecJet 110 Fuel Metering System Manual 26185 The Position Hold feature requires a valid flow command for position hold to function. The command is not used for positioning, but in order to control the position, the flow command must be valid. The position limiter function is also active so it may not be possible to achieve the desired position without increasing the flow demand.
  • Page 29 Minimum proof pressure for the TecJet 110 is 0.41 bar gauge. Minimum burst pressure for the TecJet 110 is 1.38 bar gauge.
  • Page 30 ±20% of the mass flow demand. Throughout the load range, from idle to 100% load, the TecJet 110 regulates the fuel delivery accurately relative to the fuel flow demand in order to reduce combustion emissions and protect the engine against detonation.

  • Page 31: Chapter 4. Valve Sizing

    (kg/h). Reduced this value by 10% to ensure that the TecJet 110 will handle the minimum flow requirement under all conditions. Find this reduced flow value on the right-side Y- axis of the graph.

  • Page 32: Figure 4-1. Maximum And Minimum Specialty Gas Flow Capacity Of Tecjet 110

    TecJet 110 Fuel Metering System Manual 26185 Figure 4-1. Maximum and Minimum Specialty Gas Flow Capacity of TecJet 110, 50 Plus, and 50 Woodward...

  • Page 33: Figure 4-2. Maximum And Minimum Natural Gas Flow Capacity Of Tecjet 110

    Manual 26185 TecJet 110 Fuel Metering System Figure 4-2. Maximum and Minimum Natural Gas Flow Capacity of TecJet 110, 50 Plus, and 50 Woodward...

  • Page 34: Chapter 5. Troubleshooting

    TecJet 110 Fuel Metering System Manual 26185 Chapter 5. Troubleshooting The tables in this chapter refer to status indications, warnings, and errors that can be viewed on the service tool. See Chapter 6 for information on installing the service tool.
  • Page 35 Manual 26185 TecJet 110 Fuel Metering System STATUS INDICATIONS Status Description Possible Cause Possible Actions Zero Flow If the CAN Flow ECM is requesting zero Status indication, no action Detected Demand Failed flow. required. (Flow demand warning is not active,...
  • Page 36 TecJet 110 Fuel Metering System Manual 26185 WARNINGS Warning Description Possible Cause Possible Actions Analog Flow The analog flow Analog input wiring Check the analog input Demand High demand exceeds the problem. wiring for shorts, open analog flow demand connections and maximum fail limit.
  • Page 37 Manual 26185 TecJet 110 Fuel Metering System WARNINGS Warning Description Possible Cause Possible Actions Coil Current There is an internal Internal fault. Replace valve. High problem with either the torque motor that operates the valve or with the electronics used to control the torque motor.
  • Page 38 TecJet 110 Fuel Metering System Manual 26185 WARNINGS Warning Description Possible Cause Possible Actions Electronics The internal Internal fault. Replace the valve. Temperature electronics temperature sensor has failed to a low value. The valve may not reach specified performance. Fuel Gas...
  • Page 39 Manual 26185 TecJet 110 Fuel Metering System WARNINGS Warning Description Possible Cause Possible Actions Fuel Gas The Fuel Gas Internal fault. Replace valve. Temperature Temperature sensor Sensor Low has failed to a low value and the default fuel gas temperature is being used instead.
  • Page 40 TecJet 110 Fuel Metering System Manual 26185 ERRORS When an error occurs, the valve closes, if possible. It will not attempt to operate again until power to the valve is cycled. If the error persists, the valve must be replaced.

  • Page 41: Chapter 6. Service Tool Installation

    Chapter 6. Service Tool Installation Detailed information on the TecJet™ 110 is contained in the TecJet Service Tool, which can be found on the web at: www.woodward.com/software. Select software product “TecJet Tools”. Follow the installation instructions given on that page.

  • Page 42: Chapter 7. Maintenance

    There are no components of the TecJet that are replaceable or serviceable. Make sure that the power is disconnected before removing the TecJet 110 main connector. A petrochemical solvent is recommended to clean (wash and brush) the valve when minimal film/patina build up is observed.
  • Page 43 Manual 26185 TecJet 110 Fuel Metering System • Fill the TecJet again with fresh 60 °C tap water and move the water around in the valve bore with a long plastic rod or equivalent. • Dump the rinse water out of the TecJet.

  • Page 44: Chapter 8. Service Options

    A Recognized Turbine Retrofitter (RTR) is an independent company that does both steam and gas turbine control retrofits and upgrades globally, and can provide the full line of Woodward systems and components for the retrofits and overhauls, long term service contracts, emergency repairs, etc.

  • Page 45: Woodward Factory Servicing Options

    Flat Rate Remanufacture: Flat Rate Remanufacture is very similar to the Flat Rate Repair option with the exception that the unit will be returned to you in “like- new” condition and carry with it the full standard Woodward product warranty (Woodward Product and Service Warranty 5-01-1205). This option is applicable to mechanical products only.

  • Page 46: Returning Equipment For Repair

    To prevent damage to electronic components caused by improper handling, read and observe the precautions in Woodward manual 82715, Guide for Handling and Protection of Electronic Controls, Printed Circuit Boards, and Modules.

  • Page 47: Engineering Services

    Manual 26185 TecJet 110 Fuel Metering System Engineering Services Woodward offers various Engineering Services for our products. For these services, you can contact us by telephone, by email, or through the Woodward website. • Technical Support • Product Training •...

  • Page 48: Technical Assistance

    Type of Fuel (gas, gaseous, steam, etc) Rating Application Control/Governor Information Please list all Woodward governors, actuators, and electronic controls in your system: Woodward Part Number and Revision Letter Control Description or Governor Type Serial Number Woodward Part Number and Revision Letter...
  • Page 49 Manual 26185 TecJet 110 Fuel Metering System Woodward...
  • Page 52 Email and Website—www.woodward.com Woodward has company-owned plants, subsidiaries, and branches, as well as authorized distributors and other authorized service and sales facilities throughout the world. Complete address / phone / fax / email information for all locations is available on our website.
