- Page 1 Product Manual 04176 (Revision G, 8/2015) Original Instructions ProAct™ II Electric Powered Actuator and Driver Installation and Operation Manual...
- Page 2 Revisions—Changes in this publication since the last revision are indicated by a black line alongside the text. Woodward reserves the right to update any portion of this publication at any time. Information provided by Woodward is believed to be correct and reliable. However, no responsibility is assumed by Woodward unless otherwise expressly undertaken.
-
Page 3: Table Of Contents
Product Service Options ..................24 Returning Equipment for Repair ................25 Replacement Parts ....................25 Engineering Services .................... 26 Contacting Woodward’s Support Organization ............ 26 Technical Assistance .................... 27 II A ........28 CTUATOR RIVER PECIFICATIONS .................. - Page 4 Figure 1-1. Outline Drawing of ProAct II Driver with IP56 Box ....... 6 Figure 1-2. Outline Drawing of ProAct II Driver with Sheet Metal Box ....7 Figure 1-3. Outline Drawing of ProAct Actuator ............. 8 ...
-
Page 5: Warnings And Notices
Start-up On- and off-highway Mobile Applications: Unless Woodward's control functions as the supervisory control, customer should install a system totally independent of the prime mover control system that... -
Page 6: Electrostatic Discharge Awareness
Do not touch the components or conductors on a printed circuit board with your hands or with conductive devices. To prevent damage to electronic components caused by improper handling, read and observe the precautions in Woodward manual 82715 , Guide for Handling and Protection of Electronic Controls, Printed Circuit Boards, and Modules. -
Page 7: Chapter 1. General Information
General Information Introduction The ProAct II driver converts either a 0–200 mA, 4–20 mA, 4–13 mA, 11–20 mA, PWM, or a 0–5 V control signal from a Woodward electronic control into a specific actuator position. The driver provides a feedback of 0.5–4.5 V corresponding to actuator position. -
Page 8: Figure 1-1. Outline Drawing Of Proact Ii Driver With Ip56 Box
ProAct II Actuator/Driver Manual 04176 Figure 1-1. Outline Drawing of ProAct II Driver with IP56 Box Woodward... -
Page 9: Figure 1-2. Outline Drawing Of Proact Ii Driver With Sheet Metal Box
Manual 04176 ProAct II Actuator/Driver Figure 1-2. Outline Drawing of ProAct II Driver with Sheet Metal Box Woodward... -
Page 10: Figure 1-3. Outline Drawing Of Proact Actuator
ProAct II Actuator/Driver Manual 04176 Figure 1-3. Outline Drawing of ProAct Actuator Woodward... -
Page 11: Figure 1-4. Plant Wiring Diagram
Manual 04176 ProAct II Actuator/Driver Figure 1-4. Plant Wiring Diagram Woodward... -
Page 12: Chapter 2. Installation
The actuators are designed for installation on the engine. The actuators will generate heat, especially when stalled or during other conditions requiring maximum torque output. Maximum operating temperature for the ProAct II actuator is 100 °C (212 °F). The installer must consider the heat conductivity of the installation bracket, and the operating temperature of the ultimate heat sink to which the bracket will be attached. - Page 13 Moment of Inertia (MMOI, with inertia disc applied) is 3.67*10 in-lb- sec². ProAct II actuator stops are designed to absorb 1.1 J (10 in-lbs) of kinetic energy with 3 degrees overtravel. If the actuator travel stops are used, the linkage must be designed to allow this 3 degree overrun.
-
Page 14: Actuator Bracket
Avoid pressure washing near the shaft seals. The ProAct II actuator weighs 6.9 kg (15.23 lbs). The bracket and attaching hardware must be designed to hold the weight and to withstand the vibration associated with engine mounting. -
Page 15: Electrical Connections
(2 inches). The other end of the shields must be left open and insulated from any other conductor. DO NOT run shielded signal wires along with other wires carrying large currents. See Woodward application note 50532, Interference Control in Electronic Governing Systems, for more information. -
Page 16: Power Supply
ProAct II Actuator/Driver Manual 04176 Power Supply Power supply output must be low impedance (for example, directly from batteries). Run an insulated wire directly from the positive (+) battery terminal to the fuse and the switch as shown in Figure 2-5, then from the switch to the correct connection on the driver (see Figure 1-4). -
Page 17: Figure 2-5. Correct Wiring To Power Supply
Manual 04176 ProAct II Actuator/Driver Figure 2-5. Correct Wiring to Power Supply Figure 2-6. Incorrect Power Supply Wiring Woodward... -
Page 18: Position Feedback Adjustment
ProAct II Actuator/Driver Manual 04176 Figure 2-7. ProAct Driver Adjustment Locations Position Feedback Adjustment The driver's position feedback Gain and Offset adjustments normally don't need to be changed unless you experience feedback values outside the normal operating parameters of the driver. If the characteristic falls outside the tolerance... -
Page 19: Actuator Travel
Manual 04176 ProAct II Actuator/Driver The adjustment of the system position feedback potentiometers does not affect the positioning of the actuator relative to the position input signal, or the response of the actuator to the position input signal. Reconnect the actuator drive wires. -
Page 20: Chapter 3. Description Of Operation
Description of Operation The ProAct control system functions by receiving a position command signal from a Woodward electronic governor. The system then sends a pulse width modulated current (–12 A to +12 A) signal to the actuator, modified by signals from a position feedback, velocity, and current sensor from the actuator (Figure 3-1). -
Page 21: Actuator Position Signal
Manual 04176 ProAct II Actuator/Driver A 25-turn pot (Position Command Offset) adjusts the offset of the actuator travel when the speed control signal varies from minimum to maximum. A 25-turn pot (System Position Feedback Gain) adjusts the system position feedback gain as the actuator varies from minimum to maximum. -
Page 22: Chapter 4. Troubleshooting
ProAct II Actuator/Driver Manual 04176 Chapter 4. Troubleshooting Improper engine operation is often the result of factors other than governor operation. This chapter gives tips about engine problems which can resemble governor problems. Make sure the engine is operating correctly before making any changes in the governor. -
Page 23: Chapter 5. Technical Specifications
Technical Specifications Power Supply The power supply for the ProAct II driver is configured to operate from 20 to 32 Vdc. The minimum current level to be provided by the system will be 6 A dc and 12 A dc for up to two seconds. -
Page 24: Input Configurations
(unit battery ground referenced) of 0 to 4 V for all inputs. System Performance The performance of the driver when mated to a ProAct II actuator will be as follows: Inertia level The driver mated to a ProAct II actuator can drive inertial loads not to exceed –3... - Page 25 Manual 04176 ProAct II Actuator/Driver Actuator compliance The actuator compliance will be to reach peak steady-state torque in less than 5% of actuator full travel, external deflection of the actuator from commanded position for all supply voltages and current levels within the specified power supply ranges.
-
Page 26: Chapter 6. Product Support And Service Options
A current list of Woodward Business Partners is available at www.woodward.com/directory. Product Service Options Depending on the type of product, the following options for servicing Woodward products may be available through your local Full-Service Distributor or the OEM or Packager of the equipment system. -
Page 27: Returning Equipment For Repair
To prevent damage to electronic components caused by improper handling, read and observe the precautions in Woodward manual 82715, Guide for Handling and Protection of Electronic Controls, Printed Circuit Boards, and Modules. -
Page 28: Engineering Services
Field Service engineering on-site support is available, depending on the product and location, from one of our Full-Service Distributors. The field engineers are experienced both on Woodward products as well as on much of the non- Woodward equipment with which our products interface. -
Page 29: Technical Assistance
ProAct II Actuator/Driver Technical Assistance If you need to contact technical assistance, you will need to provide the following information. Please write it down here before contacting the Engine OEM, the Packager, a Woodward Business Partner, or the Woodward factory: General... -
Page 30: Proact Ii Actuator/Driver Specifications
–55 to +125 ºC (–67 to +257 ºF) Shock MS810C, M516.2, Procedure IV, 100 g Vibration MS810C, M514.2, Proc. VIII, 20 g (10 g in axial direct.) Mass Moment of Inertia ProAct II Actuator is 3.67*10-3 in-lb-sec² (with inertia disc applied) Woodward... -
Page 31: Revision History
Manual 04176 ProAct II Actuator/Driver Revision History Changes in Revision G— Deleted items in Input Configuration table, page 5. Marked Input Configurations 11–20, 4–13 mA, and 0–5 Volt, as no longer available. Page 22. Changes in Revision F—... -
Page 32: Declarations
ProAct II Actuator/Driver Manual 04176 Declarations Woodward... - Page 33 Email and Website—www.woodward.com Woodward has company-owned plants, subsidiaries, and branches, as well as authorized distributors and other authorized service and sales facilities throughout the world. Complete address / phone / fax / email information for all locations is available on our website.
