5.6 Configure the Network

5.6.1 IP Addresses

The Mini Field Agent has four physical Ethernet ports, one of which is designated to be a WAN. The Embedded field
agent only has one physical port, labelled either IICS Cloud Port or EFA, and it is designated to be a WAN. The
following are the default settings for these networks:
Field Agent Type Default WAN Setting
MFA DHCP
EFA 172.31.0.100,
subnet mask 255.255.0.0
VFA DHCP
By default, the Mini Field Agent's WAN interface is set to acquire an IP address from a DHCP server on the network. The
network interface settings that were automatically obtained from the DHCP server can be displayed in the Web Console.
5.6.1.1

To Identify/Change an IP Address

From the Web Console, navigate to the Technician Console, Network Configuration page. Note that there will be
1.
three tabs (WAN, LAN, and Cellular) for an MFA, only a single tab (WAN) for an EFA, and three tabs (WAN, LAN1,
and LAN2) for a VFA.
2. To identify the DHCP assigned address for an MFA or VFA, select the WAN tab, then click the Query Current Status
button.
For public disclosure
Default LAN1 Setting
192.168.1.100,
subnet mask 255.255.255.0
N/A
172.16.101.150,
subnet mask 255.255.240.0
Default LAN2 Setting
N/A
N/A
172.16.201.150,
subnet mask 255.255.240.0
