Rice Lake 520 Installation Manual page 33

PROGRM Menu
Parameter Choices
Level 2 submenus
DATE DATEFMT
DATESEP
DATESET
TIME TIMEFMT
TIMESEP
TIMESET
CONSNUM 0000000
1-9999999
CONSTUP 0000000
1-9999999
UID 0
unit ID
ACCUM ON
OFF
CKWEIGH OFF
ABS
PERCENT
COUNT ACCESS
SPLSIZ
PK HOLD OFF
NORMAL
BI-DIR
AUTO
GRAVADJ OFF
ON
MVCALIB OFF
ON
CFGPWD 0
1–9999999
SPPWD 0
1–9999999
NOTE: Only the ZERONLY parameter can be specified as ON. Individual keys can be locked or unlocked using the KLOCK and
KUNLOCK EDP commands (see Table 10.1 on page 46 for more information).
ZERONLY OFF
ON
PROMPTS PRMPT1–
PRMPT8
28 520 Installation Manual
Allows selection of date format and date separator character. See Level 3 submenu parameter
descriptions.
Use the DATESET parameter or the SD EDP command to set the date. See Section 10.0 on
page 46 for information about using the EDP commands.
Allows selection of time format and separator character. See Level 3 submenu parameter
descriptions.
Use the TIMESET parameter or the ST EDP command to set the date. See Section 10.0 on
page 46 for information about using the EDP commands.
Consecutive numbering. Allows sequential numbering for print operations. The consecutive
number value is incremented following each print operation that includes <CN> in the ticket
format. When the consecutive number is reset, it is reset to the value specified on the
CONSTUP parameter, up to seven characters.
Specifies the consecutive number start-up value used when the consecutive number is reset
by sending the KCLRCN EDP command or a CLRCN digital input. Value specified must be in
the range 0–9 999 999.
Specifies the unit identification number. Value specified can be any alphanumeric value, up to
seven characters.
Accumulator. Specifies whether the accumulator is enabled.
Checkweigh. Specifies whether checkweigh is enabled and whether set for absolute or
percent checkweigh. If set to a value other than OFF, setpoints are disabled. Digital output one
will be active (ON) when the weight is within the UNDER range, digital output two will be active
when the weight is in the ACCEPT range, and digital output three is active when the weight is
within the OVER range.
Specifies whether operator has access to piece count mode and the default sample size used
for parts counting. See Level 3 submenu parameter descriptions.
Peak hold function. Optional feature used to hold display of the highest net weight achieved
during a weighing cycle.
Gravity adjustment. Set LATITUD and ELEVATN parameters for the geographic location where
the calibration is to take place (see Figure 3-7 on page 22 for these parameters).
Compensates for the variance in gravitational pull from one location to another.
Millivolt calibration. Allows entry of calibration values in mV.
Configuration password. Specify a non-zero value to restrict access to all configuration
menus.
Setpoint password. Specify a non-zero value to restrict access to the setpoint and
checkweigh menus in operate mode.
Zero key only. Specify ON to disable all front panel keys except ZERO in normal mode. See
NOTE above.
Specify prompts for use in setpoint names (up to 16 characters). Prompts are referenced by
the NAME parameter under the SETPTS submenus; prompts appear in the secondary display
area during setpoint execution for batch type setpoints.
Table 3-6. Program Menu Parameters
Description
