Replacement Parts - Rice Lake 520 Installation Manual

2.9

Replacement Parts

Table 2-5 lists replacement parts for the 520, including all parts referenced in Figures 2-2 through 2-4.
Ref
Number PN
1 68719 Gasket, Faceplate
2 68718 Overlay, Membrane switch
3 68717 Shroud, Painted
4 68716 Faceplate, WLDT
5 69023 Board, ASSY 115V
— 72979 Board, ASSY 230V North America
— 72980 Board, ASSY 230V Europe
6 69024 Board ASSY, VFD display
7 42640 Screw, MACH 1/4-28 NF x 1/4
8 15626 Cable, Grip Black PG9
9 15627 Locknut, Black PCN9
10 14839 Screw, MACH 6-32NC x 1/4
11 14822 Screw, MACH 4-40NC x 1/4
12 69031 Power cord assy
13 15631 Cable Tie, 3 in Nylon
14 15134 Washer, Lock NO 8 Type A
15 45043 Wire, Ground 4 in W/NO 8
16 14626 Kep nuts, 8-32NC hex (3)
18 16892 Label, Earth Ground IQ310
19 69091 Cable ribbon, display
21 53308 Label Roll, 1.25 x 1.25
22 69291
23 53307 Label, 4.000 x 2.875
24 54356 Screw, MACH 8-32NC x 3/8
25 71001 Lens, Polycarbonate
26 68216 Nameplate, Rice Lake
27 71616 Label, 520 J1-J3 CONN
— 69033 Parts Kit, 520 Panel Mount
— 45484
— 73001
— 45107
* Additional parts included in parts kit.
To protect against the risk of fire, replace fuses only with same type and rating fuse.
Caution
See Section 13.14 on page 81 for complete fuse specifications.
There is a risk of explosion if battery is replaced by an incorrect type.
Caution
10 520 Installation Manual
Description (Quantity)
Battery, Panasonic CR1632 Lithium
Caution
Coin
160 ma time-lag TR5 type fuse -
Caution
115V unit
Fuse - 230V unit North America
Caution
Fuse - 230V unit Europe
Caution
Table 2-5. Replacement Parts
Figure
Figure 2-2 on page 11.
