2.4 Powering the board and installation procedure for CCS v5 and CCS v6

The XDS100v3 board is powered via the mini USB.

A. Install Code Composer Studio 5.1.x (or newer) before connecting XDS100 USB hardware.

B. Install the EmuPack with XDS100v3 support. It is usually downloaded via the update button.

C. Connect the XDS100 hardware

1. Make sure the Code Composer Studio v5.1.x (or newer) and EmuPack with XDS100v3

support is installed FIRST before plugging in the XDS100 HW to the PC.

2. Connect USB cable from the PC to the XDS100 hardware. Connect the JTAG to the

target board (be careful to plug it in correctly: pin 1 should go to pin 1. Red strip usually

indicates the side of pin 1)

3. You will notice small popups to inform user that USB hardware is recognized and

installed correctly. No input are required.

D. Setup Code Composer Studio v5.1.x

4. Start Code Composer Studio and create a new target configuration.

5. Select XDS100v3 as connection type

6. Select device (target).

E. The configuration of the emulator in CCS v5.1.x is shown below (the one in CCS v6 is quite

similar):
