- Page 1 ARB® UTILITY MANAGEMENT SYSTEMS™ WATER GAS | ELECTRIC HP PROTECTUS ® Installation and Maintenance Guide...
- Page 2 ARB® UTILITY MANAGEMENT SYSTEMS™ WATER GAS | ELECTRIC HP PROTECTUS ® Installation and Maintenance Guide...
- Page 3 This manual is an unpublished work and contains the trade secrets and confidential information of Neptune Technology Group Inc., which are not to be divulged to third parties and may not be reproduced or transmitted in whole or part, in any form or by any means, electronic or mechanical, for any purpose, without the express written permission of Neptune Technology Group Inc.
-
Page 4: Table Of Contents
OVERVIEW Contacting Technical Support ........................... 1-1 INSTALLING HP PROTECTUS III Installation Instructions ............................2-1 Recommended Installation ..........................2-1 Before Operation..............................2-2 MAINTENANCE Maintenance Instructions...........................3-1 HP Turbine Meters............................3-1 Adjusting the Calibration Vane ..........................3-2 T-10 Disc Meters ............................3-3 Detector Check Valves ...........................3-3 Strainer ................................3-3 HP PROTECTUS INSTALLATION AND MAINTENANCE GUIDE... - Page 5 .........................................
-
Page 6: Overview
CONTACTING TECHNICAL SUPPORT If you encounter any problems with the installation or operation of your HP PROTECTUS III, please call Neptune at (334) 283-6555 and ask to speak with an Applications Engineer. HP PROTECTUS INSTALLATION AND MAINTENANCE GUIDE... - Page 7 .........................................
-
Page 8: Installing Hp Protectus
If a Neptune meter is installed without a strainer, a minimum of eight (8) to ten (10) pipe diameters of straight run pipe (can include components that are fully open in their normal operating position) is required upstream of the meter inlet and four (4) diameters downstream. -
Page 9: Before Operation
In particular, all gaskets should be centrally located on their flanges with no overlap or interference with the pipe diameter. The HP PROTECTUS III Meter Assembly must operate in a completely filled line at all times. The downstream piping must always provide sufficient back pressure to maintain a full line at the meter. -
Page 10: Maintenance
CHAPTER MAINTENANCE If you find that your HP PROTECTUS III is not operating as expected when installed, use the following guidelines to try to determine the source of the problem. MAINTENANCE INSTRUCTIONS HP TURBINE METERS When maintenance is necessary, the complete unitized measuring element (UME) may be quickly and easily interchanged with a factory-calibrated unit by following these steps: Close all valves (mainline and bypass). -
Page 11: Adjusting The Calibration Vane
ADJUSTING THE CALIBRATION VANE Neptune equips all new turbine meters and UMEs with a calibration vane. Should field calibration of the turbine element be required, the following steps should be followed: Remove seal pin from register and twist off register. -
Page 12: T-10 Disc Meters
Inspect valve for obstructions. Move clapper manually to ensure freedom of movement. Replace valve top cover. If further servicing is necessary, contact Neptune Customer Support. STRAINER For maximum efficiency, determine length of time it takes for baskets to become approximately one-third clogged. - Page 13 .........................................
- Page 14 11570 México, Distrito Federal TAKE CONTROL Fax: (905) 858-0428 Tel: (525) 55203 5294 / (525) 55203 5708 Fax: (525) 55203 6503 neptunetg.com IM PROTIII 08.09 © Copyright 2009, Neptune Technology Group Inc. Neptune is a registered trademark of Neptune Technology Group Inc.
