DIMENSIONS

D21
Sink clearance
With Side kits
D21 Top View - Section with Plumbing Drawer
10-1/2" / 22-1/2" / 28-1/2" / 34-1/2"
Sink clearance
(267 mm / 572 mm / 724 mm / 876 mm)
With Side kits
12-1/8" / 24-1/8" / 30-1/8" / 36-1/8"
(308 mm / 613 mm / 765 mm / 918 mm)
D21 Top View - Section with Full Drawer
Sink clearance
7-1/2"
(191 mm)
With Drawer
Front
D21 Cross-section with drawer
© 2018 Robern, Inc. 701 N. Wilson Ave. Bristol, PA 19007 U.S.A.
800.877.2376 www.robern.com
Installation instructions
22-1/2" / 28-1/2" / 34-1/2"
(572 mm / 724 mm / 876 mm)
6-1/8"
(156 mm)
24-1/8" / 30-1/8" / 36-1/8"
(613 mm / 765 mm / 918 mm)
18-1/2"
(470 mm)
7/8"
(22 mm)
21-3/4"
(552 mm)
D18
Sink clearance
15-3/8"
(391 mm)
With Side kits
Sink clearance
With Side kits
2-3/4"
Sink clearance
(70 mm)
5-1/2"
(140 mm)
With Drawer
Front
5
22-1/2" / 28-1/2" / 34-1/2"
(572 mm / 724 mm / 876 mm)
6-1/8"
(156 mm)
24-1/8" / 30-1/8" / 36-1/8"
(613 mm / 765 mm / 918 mm)
D18 Top View - Section with Plumbing Drawer
10-1/2" / 22-1/2" / 28-1/2" / 34-1/2"
(267 mm / 572 mm / 724 mm / 876 mm)
12-1/8" / 24-1/8" / 30-1/8" / 36-1/8"
(308 mm / 613 mm / 765 mm / 918 mm)
D18 Top View - Section with Full Drawer
15-1/2"
(394 mm)
7/8"
7-1/2"
(191 mm)
18-3/4"
(476 mm)
D18 Cross-section with drawer
Part no. 209-1231-D-Cartesian, Profiles H1 rev. 05/16/18
Cartesian™ Vanity, and Profiles™ Vanity
12-3/8"
(314 mm)
2-3/4"
(70 mm)
(22 mm)
2-1/2"
(64 mm)
