DRAWER INSTALLATION
1. Lay the drawer onto the drawer slides as shown (Fig.1).
2. Push the drawer in until an audible sound, a series of clicks, is heard on each side (Fig. 2).
3. Ensure that the locking pin on the back of the drawer slides engage the drawer on both sides, and that the clips are firmly engaged
before letting go of the drawer.
1 2
