Techkon SpectroDrive Manual page 13

• Single measurements can be easily taken by
removing the measurement device from the
horizontal track, positioning it on a color patch
and pressing the green button.
Paper white calibration
• A paper white calibration can be carried out by
keeping the green button pressed for a few seconds.
The measurement aperture has to be on top of a
non-printed area of the sheet.
It can be performed with SpectroDrive on the track as well
as with the measurement device taken off the track.
Automatic turn off
• When the device is not located at the left holder in the charging position and is
not in use it will switch off automatically after two minutes. It can be reactivated by
pressing the green button on the device.
LED Indicator
The rectangular LED on top of the device will appear in different colors dependent
on the device status:
Home position
Green (flashing) Blue (+ multicolor)
In home position the device is in contact with the charging station. During charging
the LED will be green and flashing. It will turn to a short-flashing green when
the battery is fully charged.Thanks to the charging management there will be no
overcharging of the battery.
Page 13
Scan-mode Single measurement
Manual TECHKON SpectroDrive Chapter 3 - How to use SpectroDrive
Paper calibration
Magenta
Error
White Red (flashing)
