TypeS DUOVIEW User Manual

Front and rear camera system
Hide thumbs

Advertisement

Table of Contents

DUOVIEW
FRONT AND REAR CAMERA SYSTEM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DUOVIEW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TypeS DUOVIEW

Summary of Contents for TypeS DUOVIEW

  • Page 1 DUOVIEW FRONT AND REAR CAMERA SYSTEM...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Introduction ....................................1 2. Package Contents ..................................2 3. Product Specifications ................................3 4. Safety Information ..................................5 5. Operation ......................................6 6. Settings ......................................9 7. Viewing Files ....................................12 8. Warranty ......................................13 9. General information ...................................17...

  • Page 3: Introduction

    1. INTRODUCTION The Type S Duoview is a video recording camera intended to capture incidents while driving. The 3” LCD is convenient for instant playback. Simply mount the camera as directed and use loop recording to capture events while driving.

  • Page 4: Package Contents

    2. PACKAGE CONTENTS 1. Duoview Dash Cam 2. Duoview Rear Cam with 6m cable 3. Suction Cup Mount for Camera 4. 12V/24V USB Charger 5. USB Cable for PC 6. 16GB SD Card (Class 10) 7. User’s Manual DUOVIEW FRONT AND REAR CAMERA SYSTEM...

  • Page 5: Product Specifications

    3. PRODUCT SPECIFICATIONS Sensor 3M CMOS sensor Camera Lens Wide angle 120 degrees, the maximum aperture: F2.3 Lens of Low Illumination 2.0v / (Lux.sec) sensitivity LCD Screen 3 inch 16:9 TFT LCD Video Output HDMI interfaces: HDMI output up to 1920x1080 Camera Resolution Full HD 1080P (1920 x 1080) 30 FPS HD 720P (1280 x 720) 30 FPS...
  • Page 6 REC/ Con rm Power/ Menu/ Capture Switch (MODE)/ Lock Rear Camera MODE REC/ Up/ SlowPlay/Switch Charging/ Down/ Fast forward/ O USB Out REC Indicator HDMI Out Mirco SD Storage card Reset Plug Suction Cup Mount IR Light 1080P FULL VIDEO RECORDER Speaker...

  • Page 7: Safety Information

    4. SAFETY INFORMATION a. Please read all safety warnings listed in this user’s manual. b. Do not operate or adjust the camera while driving. The camera should be set prior to operating the vehicle. c. Make sure the camera is not blocking the driver’s line of sight and check local laws and regulations for placement instructions.

  • Page 8: Operation

    5. OPERATION Installation Select the Duoview Position Insert the Micro SD Card Suggested placement is to the side of your rearview mirror on the front windshield Select the Rearview Camera Position Suggested placement is at the top of the rear view window.
  • Page 9 Duoview Installation (Front Windshield) Attach the mount with cam to the Connect mount to windshield the Duoview Connect Power Adapter Power using a 12V/24V Socket...
  • Page 10 Rearview Cam Installation (Rear Window) Mount the camera to the inside of the rear window using the tape provided Adjust camera angle to get the best view Plug the other end of the connection cable to the Duoview...

  • Page 11: Settings

    SWITCHING VIEWS Press the key to cycle through the following views: duoview > front view > rear view. LOOP RECORD • This is the default recording setting. The camera will start recording video automatically once it is turned on.
  • Page 12 Loop Record Setting: Select from 1 minute to 20 minutes. Use the key to save your selection, and press the key to exit and to record. The default is 3 minutes. Audio Record: Choose On or Off, and press the key to save the settings.
  • Page 13 PLAYBACK • Press key to select video / voice / photo • Press to playback video, during playback video, press key to fast forward or rewind, press again to stop playback. SYSTEM SETTINGS Date/Time Setting: Press to enter Date/Time setting. Press key to save the settings.

  • Page 14: Viewing Files

    7. VIEWING FILES a. Connect the camera to your PC with the provided mini USB to USB connector; you can also view the Micro SD card on your PC b. On your PC open up DCIM and you can view videos and pictures in the folder c.

  • Page 15: Warranty

    8. WARRANTY WINPLUS NORTH AMERICA LIMITED WARRANTY Winplus North America warrants, to the original purchaser, that its products are free from defects in material and workmanship for 1 year from the date of original purchase. Where permitted by law, Winplus North America’s liability shall be limited to that set forth in this limited express warranty.
  • Page 16 Winplus North America and/or its affiliates do not guarantee or promise that the user of Duoview will not be in an accident or otherwise not collide with an object and/or person. Our Duoview is not intended in any way to be a substitute for careful and cautious driving or for the consistent adherence to all applicable traffic...
  • Page 17 The Duoview is not intended to be a substitute for rearview mirrors or for any other motor vehicle equipment mandated by law. Even when properly installed, our Duoview has a limited field of vision and does not provide a comprehensive view of the rear area of the vehicle. You should always look around outside your vehicle and use your mirrors to confirm rearward clearance and that your vehicle can back up safely.
  • Page 18 OWNER’S RESPONSIBILITIES: In order to provide you with the proper warranty service, we request that you adhere to the following procedure: 1. Include a copy of your sales receipt or bill of sale with your unit when it is returned for warranty service.

  • Page 19: General Information

    9. GENERAL INFORMATION Declaration of Conformity Winplus North America Inc. Address: 820 South Wanamaker Avenue, Ontario, CA 91761 Tel: 866-294-9244 FCC compliance statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
  • Page 20 NORTH AMERICA 820 South Wanamaker Avenue, Tel: 866-294-9244 Ontario, CA 91761 Fax: 310-496-2740 EUROPE The Officers’ Mess Business Tel: 44-1223-919711 Centre,Royston Road, Duxford, Cambridgeshire, CB22 4QH AUSTRALIA 6 Prospect Place, Boronia Victoria, Tel: 61-3-8727-7600 Australia, 3155 Fax: 61-3-9720-4165 ASIA Suites 6-11, 7th Floor, Corporation Park, Tel: 852-2798-8932 11 On Lai Street, Shatin, N.T., Hong Kong Fax: 852-2795-0241...
