Hirschmann RSR20-0900 User Manual

Installation industrial ethernet rail switch rugged, rsr20/rsr30 family
Hide thumbs
Table of Contents

Advertisement

Quick Links

User Manual
Installation
Industrial Ethernet Rail Switch Rugged
RSR20/RSR30 Family
5
6
7
8
9
10
Installation RSR20/RSR30
Release 04 10/2015
3
4
5
6
7
8
9
10
3
4
5
6
7
8
5
6
7
8
9
10
3
4
5
6
7
8
9
10
1
2
3
4
5
6
7
8
Technical Support
https://hirschmann-support.belden.eu.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RSR20-0900 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hirschmann RSR20-0900

Summary of Contents for Hirschmann RSR20-0900

  • Page 1 User Manual Installation Industrial Ethernet Rail Switch Rugged RSR20/RSR30 Family Installation RSR20/RSR30 Technical Support Release 04 10/2015 https://hirschmann-support.belden.eu.com...
  • Page 2 This publication was created by Hirschmann Automation and Control GmbH to the best of its knowledge. Hirschmann reserves the right to change the content of this publication at any time without notice. Hirschmann does not give any warranty or assurance with respect to the correctness or accuracy of the details in this publication.

  • Page 3: Table Of Contents

    Content Safety Information About this manual Description General description of the device Description of the device variants 1.2.1 Combination options RSR20/RSR30 1.2.2 Port number and media for RSR20-... 1.2.3 Port number and media for RSR30-... Power supply 1.3.1 Supply voltage with the characteristic value K 1.3.2 Supply voltage with the characteristic value C Ethernet ports 1.4.1 10/100/1000 Mbit/s twisted pair port...
  • Page 4 2.4.1 Supply voltage 2.4.2 Supply voltage with the characteristic value K 2.4.3 Supply voltage with the characteristic value C 2.4.4 Signal contact Mounting a terminal block Operating the device Connecting data cables Insert data in label area Making basic settings Monitoring the ambient air temperature Maintenance and service Disassembly...

  • Page 5: Safety Information

    Intended usage   Use the product only for the application cases described in the Hirschmann product information, including this manual.  Operate the product only according to the technical specifications. See “General technical data” on page 54.  Connect to the product only components suitable for the requirements of the specific application case.
  • Page 6 Device casing  Only technicians authorized by the manufacturer are permitted to open the casing.  Never insert pointed objects (narrow screwdrivers, wires, etc.) into the device or into the connection terminals for electric conductors. Do not touch the connection terminals. ...
  • Page 7 Supply voltage  The supply voltage is electrically isolated from the housing.  The devices are designed for operation with safety extra-low voltage. Connect only safety extra-low voltage circuits with voltage restrictions in line with IEC/EN 60950-1 to the supply voltage connections and signal contacts.
  • Page 8  Only for device variants featuring supply voltage with the characteristic value C:  The power supply is Class 2 compliant.  The power supply conforms to overvoltage category I or II.  The voltage supply has an easily accessible disconnecting device (e.g.
  • Page 9 Relevant for use in explosion hazard areas (Hazardous  Locations, Class I, Division 2): SUITABLE FOR USE IN CLASS I, DIVISION 2, GROUPS A, B, C AND D HAZARDOUS LOCATIONS, OR IN NON-HAZARDOUS LOCATIONS ONLY. Substitution of any components may impair suitability for Class I, Division 2.
  • Page 10 Installation RSR20/RSR30 Release 04 10/2015...
  • Page 11 Installation RSR20/RSR30 Release 04 10/2015...
  • Page 12 In accordance with the above-named EU directive(s), the EU conformity declaration will be at the disposal of the relevant authorities at the following address: Hirschmann Automation and Control GmbH Stuttgarter Str. 45-51 72654 Neckartenzlingen Tel.: +49 1805 141538 The product can be used in the industrial sector.
  • Page 13 Warning! This is a class A device. This device can cause interference in living areas, and in this case the operator may be required to take appropriate measures. LED or laser components  LED or LASER components according to IEC 60825-1 (2014): CLASS 1 LASER PRODUCT CLASS 1 LED PRODUCT FCC note...

  • Page 14: About This Manual

    About this manual The document “User Manual Installation” contains a device description, safety instructions, a description of the display and further information that you need to install the device before you start its configuration. The following manuals are available as PDF files on the CD-ROM supplied: ...

  • Page 15: Key

    The symbols used in this manual have the following meanings:  List Work step  Subheading  Installation RSR20/RSR30 Release 04 10/2015...

  • Page 16: Description

    Description General description of the device You can choose from between a wide range of variants. You have the option to set up your device individually based on different criteria:  Number of Ports  Data Rate  Types of connectors ...

  • Page 17: Description Of The Device Variants

    You will find these manuals in the form of PDF files on the enclosed CD/DVD; it is also available for downloading on the Internet on the Hirschmann product pages (www.hirschmann.com). The Hirschmann network components help you ensure continuous communication across all levels of the enterprise.
  • Page 18 Position Characteristic Charac Property teristic value 1 to 5 Product RSR20 Rail Switch Rugged without gigabit ports RSR30 Rail Switch Rugged with gigabit ports - (hyphen) 7 to 8 Number of 100 Mbit/s 6 × 100 Mbit/s Ethernet ports 7 × 100 Mbit/s Ethernet 8 ×...
  • Page 19 Position Characteristic Charac Property teristic value 13 and 14 Port 2 or Port 3 or 2 × SFP slot (100 Mbit/s) Port 3 and 4 1 × Combo-Port 100/1000 Mbit/s Ethernet 1 × SFP slot 1000 Mbit/s Ethernet 1 × Twisted Pair TX (RJ45 socket) 1 ×...

  • Page 20: Port Number And Media For Rsr20

    -“- -“- -“- -“- -“- -“- -“- -“- -“- -“- -“- -“- Table 2: Combination options for RSR20-0900... Position Position Position Position Position Position Position 1 to 10 11 to 12 13 to 14 15 to 16 18 to 19...
  • Page 21 Supply voltage connection 1 Alternatively Product code 2-pin terminal block , depending Position 18 Voltage range: on device See “General technical data” on page 54. variant 3-pin terminal block Voltage range: See “General technical data” on page 54. LED display elements for device status USB interface Connection for signal contact 1 V.24 connection for external management...
  • Page 22 1 to 9 See table 4 on page 21. Port 3 to 8 LAN port for Standard IEEE 802.3 10BASE-T/100BASE-TX Twisted pair Connection RJ45 socket type Port 1 to 2 LAN port for Standard IEEE 802.3 100BASE-FX Optical fiber Connection depending on the type device variant...
  • Page 23 1 to 9 See table 4 on page 21. Port 1 to 8 LAN port for Standard IEEE 802.3 10BASE-T/100BASE-TX Twisted pair Connection RJ45 socket type Table 6: RSR20 device variants with 8 twisted pair ports (RJ45) Installation RSR20/RSR30 Release 04 10/2015...
  • Page 24 1 to 9 See table 4 on page 21. Port 4 to 9 LAN port for Standard IEEE 802.3 10BASE-T/100BASE-TX Twisted pair Connection RJ45 socket type Ports 1 to 3 LAN port for Fiber type Multimode Optical fiber Standard IEEE 802.3 100BASE-FX Connection MTRJ type...

  • Page 25: Port Number And Media For Rsr30

    1.2.3 Port number and media for RSR30-... To put together your personal RSR30 device in the above table (see table you have the following combination options (“?” = any value from the “Characteristic value column): Position Position Position Position Position Position Position 1 to 10...
  • Page 26 1 to 9 See table 4 on page 21. Port 4 to 9 LAN port for Standard IEEE 802.3 10BASE-T/100BASE-TX Twisted pair Connection RJ45 socket type Ports 1 to 3 LAN port for Standard IEEE 802.3 100BASE-FX (Combo Optical fiber ISO/IEC 8802-03 1000BASE-SX/LX ports) Connection...
  • Page 27 1 to 8 See table 4 on page 21. Port 4 to 10 LAN port for Standard IEEE 802.3 100BASE-FX Optical fiber Connection SFP slot type Ports 1 to 3 LAN port for Standard ISO/IEC 8802-03 1000BASE-SX/LX Optical fiber Connection SFP slot type LED display elements for port status...
  • Page 28 1 to 9 See table 4 on page 21. Port 5 to 10 LAN port for Standard IEEE 802.3 10BASE-T/100BASE-TX Twisted pair Connection RJ45 socket type Port 3 to 4 LAN port for Standard IEEE 802.3 100BASE-FX Optical fiber Connection SFP slot type Port 1 to 2...
  • Page 29 1 to 9 See table 4 on page 21. Port 5 to 10 LAN port for Standard IEEE 802.3 10BASE-T/100BASE-TX Twisted pair Connection RJ45 socket type Port 3 to 4 LAN port for Standard IEEE 802.3 100BASE-FX Optical fiber Connection SFP slot type Port 1 to 2...
  • Page 30 1 to 9 See table 4 on page 21. Port 3 to 10 LAN port for Standard IEEE 802.3 10BASE-T/100BASE-TX Twisted pair Connection RJ45 socket type Port 1 to 2 LAN port for Standard IEEE 802.3 100BASE-FX (Combo Optical fiber ISO/IEC 8802-03 1000BASE-SX/LX ports) Connection...
  • Page 31 1 to 9 See table 4 on page 21. Port 3 to 10 LAN port for Standard IEEE 802.3 10BASE-T/100BASE-TX Twisted pair Connection RJ45 socket type Port 1 to 2 LAN port for Standard ISO/IEC 8802-03 1000BASE-SX/LX Optical fiber Connection SFP slot type Table 16: RSR30 device variants with 2 SFP slots and 8 twisted pair ports (RJ45)

  • Page 32: Power Supply

    Power supply You will find information on the characteristic values here: “Combination options RSR20/RSR30” on page 17 1.3.1 Supply voltage with the characteristic value K A 3-pin terminal block is available for the power supply to the device. For more details, see “Supply voltage with the characteristic value K”...

  • Page 33: 10/100 Mbit/S Twisted Pair Port

    1.4.2 10/100 Mbit/s twisted pair port This port is an RJ45 socket. The 10/100 Mbit/s twisted pair port offers you the ability to connect network components according to the IEEE 802.3 10BASE-T/100BASE-TX standard. This port supports:  Autonegotiation  Autopolarity ...

  • Page 34: 100 Mbit/S F/O Port

    1.4.5 100 Mbit/s F/O port This port is an MTRJ, ST, or DSC socket. The 100 Mbit/s F/O port offers you the ability to connect network components according to the IEEE 802.3 100BASE-FX standard. This port supports:  Full or half duplex mode Delivery state: full duplex Note: Verify that the LH ports are connected exclusively with LH ports, SM ports exclusively with SM ports, and MM ports exclusively with MM ports.

  • Page 35: Pin Assignments

    1.4.7 Pin assignments RJ45 10/100 Mbit/s 1000 Mbit/s MDI mode BI_DA+ Positive V TX− BI_DA− Positive V BI_DB+ Negative V — BI_DC+ Positive V — BI_DC− Positive V RX− BI_DB− Negative V — BI_DD+ Negative V — BI_DD− Negative V MDI-X mode BI_DB+ Negative V...

  • Page 36: Display Elements

    Display elements After the supply voltage is set up, the software starts and initializes itself. Afterwards, the device performs a self-test. During this process, various LEDs light up. The process takes around 40 seconds. Figure 1: LED display elements 1 – Device status 2 –...
  • Page 37 Stand-by (green LED) Meaning Glowing green Stand-by mode enabled Does not light up Stand-by mode not enabled RM and Stand-by during read or write access - display saving processes Flashing alternately Error during saving process. LEDs flash synchronously, 2 Loading the configuration from the AutoConfiguration Adapter times a second ACA or from the device.

  • Page 38: Port Status

    1.5.2 Port status These LEDs display port-related information. During the boot phase, they indicate the status of the boot process. Figure 3: Port status LEDs 1 – Port status LEDs for single or single-row RJ45 sockets: one green and one yellow LED per port 2 –...

  • Page 39: Management Interfaces

    Management interfaces 1.6.1 USB interface The USB socket has an interface for the local connection of a AutoConfiguration Adapters ACA21-M12 USB. It is used for saving/loading the configuration data and diagnostic information, and for loading the software. The USB interface has the following properties: ...

  • Page 40: Signal Contacts

    RJ11 RJ11 n.c. Figure 4: Pin assignment of the V.24 interface and the DB9 plug Note: You find the order number for the terminal cable, which is available as accessory, under “Accessories” on page You will find a description of the V.24 interface in the “User Manual Basic Configuration”...

  • Page 41: Installation

    Installation The devices have been developed for practical application in a harsh industrial environment. On delivery, the device is ready for operation. To install and configure the device, please complete the following steps:  Checking the package contents  Installing and grounding the device ...

  • Page 42: Snapping A Unit Onto The Din Rail

    Only for device variants featuring supply voltage with the characteristic value K: WARNING ELECTRIC SHOCK Install this device only in a switch cabinet or in a restricted access location, to which maintenance staff have exclusive access. Install the device at ambient temperatures greater than 113 °F (45 °C) in “restricted access locations”...

  • Page 43: Mounting On A Vertical Flat Surface

    Note: The shielding ground of the connectable twisted pair cables is connected to the lower covering panel as a conductor. 2.2.2 Mounting on a vertical flat surface You have the option of attaching the device to a vertical flat surface. You need a wall mounting plate for this, which you can purchase as an accessory.

  • Page 44: Grounding

    (AWG18). The device is grounded by the separate ground screw on the front panel. Installing an SFP transceiver (optional) Use only Hirschmann SFP transceivers which are suitable for usage with the device. See “Accessories” on page 62. Proceed as follows: ...
  • Page 45 Note: Relevant for North America: The torque for tightening the terminal block for the signal contact on the device is 3 lb-in (0.34 Nm). The torque for tightening the supply voltage terminal block on the device is 4.5 lb-in (0.51 Nm). Supply voltage connection 1 Alternatively, Product code...

  • Page 46: Supply Voltage

    2.4.1 Supply voltage In devices with two voltage inputs, the supply voltage can be connected redundantly. Both inputs are uncoupled. There is no distributed load. The supply voltage is electrically isolated from the housing. Note: With a non-redundant supply of the supply voltage, the device reports the loss of a supply voltage.

  • Page 47: Supply Voltage With The Characteristic Value C

    WARNING ELECTRIC SHOCK Install this device only in a switch cabinet or in a restricted access location, to which maintenance staff have exclusive access. Failure to follow these instructions can result in death, serious injury, or equipment damage. For every supply voltage to be connected, perform the following steps: ...

  • Page 48: Signal Contact

    For every supply voltage to be connected, perform the following steps:  Pull the terminal block off the device.  Connect the wires according to the pin assignment on the device with the clamps.  Fasten the wires connected by tightening the terminal screws. With a non-redundant supply of the supply voltage, the device reports the loss of a supply voltage.

  • Page 49: Connecting Data Cables

    Connecting data cables In general, adhere to the following recommendations for data cable connections in environments with high electrical interference levels:  Keep the length of the data cables as short as possible.  Use optical data cables for the data transmission between the buildings. ...

  • Page 50: Making Basic Settings

    Making basic settings The IP parameters must be entered when the device is installed for the first time. The device provides the following options for configuring IP addresses:  Configuration via V.24 connection  Configuration using the HiDiscovery protocol  Configuration via BOOTP ...

  • Page 51: Monitoring The Ambient Air Temperature

    Monitoring the ambient air temperature Only operate the device up to the specified maximum ambient air temperature. See “General technical data” on page 54. The ambient air temperature is the temperature of the air at a distance of 5 cm from the device. It depends on the installation conditions of the device, e.g.

  • Page 52: Maintenance And Service

    Maintenance and service  When designing this device, Hirschmann largely avoided using wear parts. The parts subject to wear and tear are dimensioned to last longer than the lifetime of the product when it is operated normally. Operate this device according to the specifications.

  • Page 53: Disassembly

    Disassembly Removing the device Proceed as follows:  Disconnect the data cables.  Disable the supply voltage.  Disconnect the terminal blocks.  Disconnect the grounding.  Insert a screwdriver horizontally below the housing into the locking gate.  Without tilting the screwdriver, pull the locking gate down and tilt the device upwards.

  • Page 54: Technical Data

    Temperature of the ambient air at a distance of 2 inches (5 cm) from the device b. Hirschmann recommends to use SFP transceivers with the “EEC” extension. c. Use only SFP transceivers with the “EEC” extension, otherwise the standard temperature range applies.
  • Page 55 Dimension drawings  inch 4.72 6,99 120,83 0.28 4.76 Drilling holes drawing for wall mounting plate  4.72 inch 0.40 3.94 0.22 0.28 Installation RSR20/RSR30 Release 04 10/2015...
  • Page 56 EMC and immunity  IEC/EN 61850- Description Approval C Approval H 3:2002 EMI TYPE tests, test in comp. with Test level Test level IEC/EN 61000-4-2 ESD Contact discharge +/- 8 kV +/- 8 kV Air discharge +/- 15 kV +/- 15 kV IEC/EN 61000-4-3 Electromagnetic field 80 - 2700MHz 20 V/m...
  • Page 57 IEEE 1613:2009 Description Approval C Approval H EMI TYPE tests, Test level Test level test in comp. with IEEE C37.90.3 Contact discharge +/- 8 kV +/- 8 kV Air discharge +/- 15 kV +/- 15 kV IEEE C37.90.2 Electromagnetic field 80 - 2700MHz 35 V/m (peak) 35 V/m (peak)
  • Page 58 EMC emitted interference Approval C Approval H EN 55022 Class A Class A FCC 47 CFR Part 15 Class A Class A Germanischer Lloyd Classification and Classification and Construction Construction Guidelines VI-7-3 Guidelines VI-7-3 Part 1 Ed.2003 Part 1 Ed.2003 Installation RSR20/RSR30 Release 04 10/2015...
  • Page 59 Network range  Note: The line lengths specified for the transceivers apply for the respective fiber data (fiber attenuation and BLP/dispersion). Product Wave Fiber System Example Fiber code length attenua- of optical attenua- Dispersion M-SFP-... tion fiber line tion length -SX/LC...
  • Page 60 Product Wave Fiber System Example Fiber BLP/ code length attenua- of optical attenua- dispersion M-FAST- tion fiber line tion SFP-... length -MM/LC... MM 1310 nm 50/125 µm 0-8 dB 0-5 km 1.0 dB/km 800 MHz×km -MM/LC... MM 1310 nm 62.5/125 µm 0-11 dB 0-4 km 1.0 dB/km 500 MHz×km...
  • Page 61 Power consumption/power output, order numbers  The order numbers correspond to the product codes of the devices. See “Combination options RSR20/RSR30” on page 17. RSR device Power Power output consumption (incl SFP (incl SFP transceivers) transceivers) 3 × combo port and 6 × TX port (100 Mbit/s) 15 W 51 Btu (IT)/h 2 ×...
  • Page 62 Accessories  Note that products recommended as accessories may have different characteristics to those of the device, which may limit the application range of the overall system. For example, if you add an accessory with IP 20 to a device with IP 65, the IP of the overall system is reduced to 20. Gigabit Ethernet SFP transceiver Order number M-SFP-TX/RJ45...
  • Page 63 Fast Ethernet SFP transceiver Order number M-FAST SFP-TX/RJ45 942 098-001 M-FAST SFP-TX/RJ45 EEC 942 098-002 The following operating conditions apply to twisted pair transceivers:  Usable with: - HiOS as of software version 03.0.00 - for PRP ports on RSP devices, as of software version 02.0.01 - for PRP ports on EES devices, as of software version 02.0.02 - Classic switch software as of software version 08.0.00 - HiSecOS ab Software-Version 01.2.00...
  • Page 64 If your device has a shipping approval according to Germanischer Lloyd, you find the approval mark printed on the device label. You find out whether your device has other shipping approvals on the Hirschmann website under www.hirschmann.com in the product information.

  • Page 65: A Further Support

     Email: inet-ap@belden.com Hirschmann Competence Center  The Hirschmann Competence Center is ahead of its competitors on three counts with its complete range of innovative services:  Consulting incorporates comprehensive technical advice, from system evaluation through network planning to project planning.

This manual is also suitable for:
