- Page 1 Installation and Operation Manual TecJet™ 50 Gas Control Valve Manual 36102 (Revision B)
- Page 2 Revisions—Text changes are indicated by a black line alongside the text. Woodward Governor Company reserves the right to update any portion of this publication at any time. Information provided by Woodward Governor Company is believed to be correct and reliable. However, no responsibility is assumed by Woodward Governor Company unless otherwise expressly undertaken.
-
Page 3: Table Of Contents
PERATION Pre-start Checks during Installation ..............11 Configuration of the TecJet 50 ................11 Installation of the TecJet 50 Monitoring Software ..........12 Description of TecJet 50 Monitoring Program............13 Description of the TecJet 50 Menus..............16 Replacement of TecJet 50 Gas Control Valve .............21 4. - Page 4 Figure 3-6. Diagnostics Menu ................15 Figure 3-7. Help Menu..................16 Figure 5-1. Flow Capacity for the TecJet 50, Version 1 ........27 Figure 5-2. Flow Capacity for the TecJet 50, Version 2 ........28 Figure 5-3. Flow Capacity for the TecJet 50, Version 3 ........28 Electrostatic Discharge Awareness All electronic equipment is static-sensitive, some components more than others.
-
Page 5: Chapter 1. General Information
The pressure over the valve • The density of the gas The TecJet 50, in combination with an engine control system, forms an ideal solution to gas engine control, regardless of gas specification (pressure, temperature, and composition). Figure 1-1. TecJet 50 Gas Control Valve... -
Page 6: Tecjet 50 Monitoring Software
200–2000 kW (depending on gas pressure and composition). NOTE In the case of variation in gas flow demand, the TecJet 50 gas control valve is able to respond extremely quickly. The benefits of such fast response result in good engine behavior—low fuel consumption, accurate emission levels, and gas flow that completely matches load demand. -
Page 7: Chapter 2. Installation
Ambient Operating Temperature The TecJet 50 must be operated within a temperature range of –20 to +85 °C (–4 to +185 °F), although the TecJet 50 will survive a soak temperature of 105 °C (221 °F) caused by engine shutdown. -
Page 8: Wiring Requirements
50 volts. The I/O cabling for the TecJet 50 should be limited to less than 30 meters in length. The TecJet 50, combined... -
Page 9: Figure 2-3. Correct Wiring To Power Supply
TecJet 50 Menus section in Chapter 3. Power Supply Requirements The input power supply to the TecJet 50 is rated at 18 to 32 Vdc, 24 Vdc nominal. It is protected from reverse voltage connections and up to +80 V on its input. -
Page 10: Figure 2-4. Incorrect Wiring To Power Supply
TecJet 50 connector will prevent disturbances and/or reflections of CAN signals. If your application consists of multiple TecJet 50’s, then pins B and S of the first TecJet 50 should be connected to pins N and V of the second TecJet 50. -
Page 11: Installation Of The Tecjet 50
Teflon tape particles during the initial start-up. CAUTION—GAS PIPE FLANGES Before installation of the TecJet 50 to the gas pipe, prepare the gas pipe with two flanges which are the same size as the flanges on the TecJet 50 (see Figure 2-8) for further details. - Page 12 • Connect the TecJet 50 flange to the flange on the gas pipe on both sides, according to DIN 2501 (DN80, PN 10/16) for Europe, or to ANSI B (16,5 3”, 125/150 lb) for North America (see Figure 2-8).
-
Page 13: Figure 2-8. Tecjet 50 External Dimensions (8407-105)
Manual 36102 TecJet 50 Figure 2-8. TecJet 50 External Dimensions (8407-105) Woodward... -
Page 14: Figure 2-9. Tecjet 50 Wiring Diagram (8407-105)
TecJet 50 Manual 36102 Figure 2-9. TecJet 50 Wiring Diagram (8407-105) Woodward... -
Page 15: Chapter 3. Operation
Always ensure that the TecJet 50 is installed using a bracket. Also check the connection between the bracket and the TecJet 50. • Check that the TecJet 50 is installed in the correct direction according to the gas flow. •... -
Page 16: Installation Of The Tecjet 50 Monitoring Software
TecJet 50 Manual 36102 Adjust the following application specific parameters of your TecJet 50 before you start the engine: Window Adjustment Fuel Parameters Window Adjust the Density of the gas. Adjust the “Wobbe index act. gas” and the “Wobbe index ref. gas”. Both Wobbe indexes must be equal to each other and set to the Wobbe index of the current gas supply to the engine. -
Page 17: Description Of Tecjet 50 Monitoring Program
(see Figure 3-2). The menu bar on the TJMON display provides a set of commands and settings to allow monitoring and configuring the TecJet 50 gas control valve. Each menu contains several options that are commands, or links to further menus. -
Page 18: Figure 3-4. View Menu
TecJet 50 Manual 36102 View Menu The “View” menu allows you to view the output parameters contained in the system. These can be either running levels or error conditions (see next section for more details). Figure 3-4. View Menu Woodward... -
Page 19: Figure 3-5. Parameters Menu
Manual 36102 TecJet 50 Parameters Menu The “Parameters” menu contains windows into which you are able to enter and modify the various fuel, flow or CAN parameters (see next section for more details). Figure 3-5. Parameters Menu Diagnostics Menu The “Diagnostics” menu provides you with the ability to access information on default tables and physical limitations (see next section for more details). -
Page 20: Description Of The Tecjet 50 Menus
To retrieve a saved set of parameter settings from the disk, select “Open” from the File menu. Save To store the TecJet 50 parameter settings to disk, select “Save” from the file menu. Save As To make a new parameter file on disk, select “Save As” from the File menu. - Page 21 Physical Limits under the Diagnostics menu. TecJet 50 State Gives the internal condition of the TecJet 50 software. If you have any problems with your TecJet 50, please mention this code to Woodward.
- Page 22 Diagnose Density Ref. Gas The Density ref. gas lets you specify the gas density. The TecJet 50 Parameters uses this parameter in the calculation of the gas flow (Qg) from the Menu / Fuel “normal”...
- Page 23 Manual 36102 TecJet 50 Menu/Window Parameter Function Analog The analog signal from 0.2–4.8 V goes through a 10-bit ADC Parameters Menu/ (analog-to-digital converter) that converts the signal to 0–1023 Flow Input Window counts. The ADC sends the 0–1023 counts signal to the scale...
- Page 24 The Harness Coding will be used if the send and receive IDs in the monitor program are set to “0”. The Harness Coding identifies four different TecJet 50 s. For this purpose, there are two pins on the TecJet 50 connector.
-
Page 25: Replacement Of Tecjet 50 Gas Control Valve
5. Discard the old sealant material or gasket from the gas pipe. 6. Put a new gasket on both sides of the TecJet 50, and install the new TecJet 7. Check the TecJet 50 connection for gas leakages by opening the manual shut-off valve and the gas shut-off solenoid valve. - Page 26 7. Discard the old sealant material from the gas pipe. 8. Put a new gasket on both sides of the TecJet 50, and install the new TecJet 9. Check the TecJet 50 connection for gas leakages by opening the manual shut-off valve and the gas shut-off solenoid valve.
-
Page 27: Chapter 4. Troubleshooting
In general, if the “Overall status OK” flag is not set (not crossed), this indicates that there is a problem with the TecJet 50 or its associated systems. A history of problems experienced can be viewed using the View/Error Log menu. Use the error log codes table in this chapter for further details of your specific error code. - Page 28 Checks for the type of PCB for sensor diagnostic. It will read to see if there is a FGP or dP active sensor. It will also check if the PWM frequency is set (this is a Woodward production item). Out of PWM Frequency Range During run-time, the PWM frequency will be checked.
-
Page 29: Messages
72 or CAN controller databus. 15 or Detected PCB type unknown. Please note that the above error will cause the message “TecJet 50 Bad” to appear on the screen. See Chapter 3 for further details of the error messages. “Status Bar”... -
Page 30: Chapter 5. Technical Specifications
TecJet 50 Manual 36102 Chapter 5. Technical Specifications TecJet™ 50 Specifications Weight 14.5 kg (32.0 lb) Power Supply Rating 18–32 Vdc Power Consumption 15 W and 40 W peak Ambient Temperature –25 to + 85 °C (–13 to +185 °F) Storage Temperature –40 to + 105 °C (–40 to +221 °F) -
Page 31: Tecjet 50 Flow Capacity
Flow = 450 * 1.221/1.03 = 532 nm³/h Flow (at 0.82) = 532 * SQR(1.03/0.82) = 596 nm³/h Maximum differential pressure (DP): 40 kPa Minimum differential pressure: 3 kPa Maximum absolute gas pressure (AP): 250 kPa Figure 5-1. Flow Capacity for the TecJet 50, Version 1 Woodward... -
Page 32: Figure 5-2. Flow Capacity For The Tecjet 50, Version 2
TecJet 50 Manual 36102 Figure 5-2. Flow Capacity for the TecJet 50, Version 2 Figure 5-3. Flow Capacity for the TecJet 50, Version 3 Woodward... -
Page 33: Chapter 6. Service Options
Product Service Options The following factory options are available for servicing Woodward equipment, based on the standard Woodward Product and Service Warranty (5-01-1205) that is in effect at the time the product is purchased from Woodward or the service is performed: •... -
Page 34: Returning Equipment For Repair
Returning Equipment for Repair If a control (or any part of an electronic control) is to be returned to Woodward for repair, please contact Woodward in advance to obtain a Return Authorization Number. When shipping the item(s), attach a tag with the following information: •... -
Page 35: Replacement Parts
To expedite the repair process, contact Woodward in advance to obtain a Return Authorization Number, and arrange for issue of a purchase order for the item(s) to be repaired. No work can be started until a purchase order is received. -
Page 36: Engineering Services
TecJet 50 Manual 36102 Engineering Services Woodward Industrial Controls Engineering Services offers the following after- sales support for Woodward products. For these services, you can contact us by telephone, by email, or through the Woodward website. • Technical Support •... -
Page 37: Technical Assistance
Type of Fuel (gas, gaseous, steam, etc) Rating Application Control/Governor Information Please list all Woodward governors, actuators, and electronic controls in your system: Woodward Part Number and Revision Letter Control Description or Governor Type Serial Number Woodward Part Number and Revision Letter... - Page 38 TecJet 50 Manual 36102 Woodward...
-
Page 39: Declarations
Declarations... - Page 40 Phone +1 (970) 482-5811 • Fax +1 (970) 498-3058 Email and Website—www.woodward.com Woodward has company-owned plants, subsidiaries, and branches, as well as authorized distributors and other authorized service and sales facilities throughout the world. Complete address / phone / fax / email information for all locations is available on our website.
