Figure 2-13. User Options Tabs
2.3

Advanced Modes

The AVR-IoT development board can be forced to enter one of a few advanced modes of operation at
start-up. These modes can be entered by pressing one or a combination of the push buttons that are
present on the board, labeled Switch 0 (SW0) and Switch 1 (SW1).
advanced modes, descriptions, physical indicators of entering a specific mode, and how to enter them.
Table 2-2. AVR-IoT WG Advanced Modes
Advanced Mode
Soft AP mode
WINC OTA mode*
Bootloader mode*
* - Not implemented in firmware code version 1.00.
©
2018 Microchip Technology Inc.
Description
Software-Enabled
Access mode enables
the WINC to be made a
wireless access point.
Enables over-the-air
WINC firmware updates.
Enables ATmega
bootloader.
User Guide
AVR-IoT WG User Guide
Chapter 2: Getting Started
Table 2-2 enumerates these
Instructions
Press and hold SW0 at
power-up.
Press and hold SW1 at
power-up.
Press and hold SW0
and SW1 at the same
time.
Physical Indicators
All lights are off
Blinking Green LED
Blinking Red LED
