2. WPA/WPA2
3. WEP
Figure 2-7. Serial Command Line Interface
Figure 2-8. Wi-Fi Authentication Example
III. USB Programmer/Debugger interface
For users familiar with the Atmel Studio interface, the AVR microcontroller can also be programmed and
debugged directly via the Atmel Studio 7.0 IDE. The AVR-IoT development board is automatically
detected by the Atmel Studio IDE, enabling full programming and debugging through the on-board
nEDBG interface.
2.2

AVR-IoT Development on START

Atmel START, a quick development tool, can be used to select and customize additional code examples
including single-click support for 100+ Click sensor boards (out of the 450 models available so far). The
codes can be downloaded by clicking Browse Examples on the Atmel START page, as shown in
2-9.
I. Generate the AVR-IoT Development Board Demo
To generate the microcontroller code used on the AVR-IoT development board, select Browse Examples
from the Atmel START home page and follow these simple steps:
©
