Object of Declaration: MCP1632 Single-Cell Li-Ion Battery Charger Demo Board 2014 Microchip Technology Inc. DS50002321A-page 3...
• Revision History DOCUMENT LAYOUT This document describes how to use the MCP1632 Single-Cell Li-Ion Battery Charger Demo Board as a development tool to emulate and debug firmware on a target board, as well as how to program devices. The document is organized as follows: •...
MCP1632 Single-Cell Li-Ion Battery Charger Demo Board User’s Guide CONVENTIONS USED IN THIS GUIDE This manual uses the following documentation conventions: DOCUMENTATION CONVENTIONS Description Represents Examples Arial font: ® Italic characters Referenced books MPLAB IDE User’s Guide Emphasized text ...is the only compiler...
Preface RECOMMENDED READING This user's guide describes how to use the MCP1632 Single-Cell Li-Ion Battery Char- ger Demo Board. Other useful documents are listed below. The following Microchip documents are available and recommended as supplemental reference resources. • MCP1632 Data Sheet – “High-Speed, Low-Side PWM Controller”...
• MCP1632 high-speed current mode PWM controller. – When used in conjunction with a microcontroller, the MCP1632 will control the power system duty cycle to provide output current and/or voltage regulation. • PIC12F1822 microcontroller (8-bit MCU) – Used to implement the charging algo- rithm and to provide additional software functions like protections.
The conversion gain of this circuit is 1V/A. The PWM output available from the PIC12F1822 microcontroller is used to control the reference voltage of the MCP1632 using the circuit created with D2 and R3 components. Maximum output current is set by the PIC12F1822 microcontroller.
DEMO BOARD USER’S GUIDE Chapter 2. Installation and Operation GETTING STARTED The MCP1632 Single-Cell Li-Ion Battery Charger Demo Board is fully assembled and tested. The board requires the use of an external input voltage source (+4.5V to +12V). 2.1.1 Additional Components Required for Operation •...
2.2.3 Powering the Board Connect a power supply to J1 to power-up the MCP1632 Single-Cell Li-Ion Battery Charger Demo Board. Ensure that the power supply has the (+) terminal connected to J2 terminal block at pin 1 (up) and (–) terminal connected to pin 2 (down). The input voltage source should be limited to the 4.5V to 12V range.
EVALUATING THE APPLICATION The best way to evaluate the MCP1632 Single-Cell Li-Ion Battery Charger Demo Board is to examine the circuit and measure voltages and currents with a Digital Voltage Meter (DVM) and probe the board with an oscilloscope. Additional tools are necessary to evaluate some technical parameters of the board (temperature of power components, ability to withstand surge voltage pulse on input, EMI).
MCP1632 Single-Cell Li-Ion Battery Charger Demo Board User’s Guide 2.4.1 Main Loop Description The charger state machine is hardware independent, so all the output regulation is done in the main loop. Besides calling the state machine every second, different parameters and macros are required for the state machine code.
= 4.2V Sense Idle Mode 2 Constant Voltage (4.2V) < I Sense Bat_Detect Time Out? < I Sense Flat Standby Battery_Standby_Mode < V Sense Bat_Detect < Topping_Voltage Sense FIGURE 2-3: The Charger State Machine. 2014 Microchip Technology Inc. DS50002321A-page 17...
Page 18
MCP1632 Single-Cell Li-Ion Battery Charger Demo Board User’s Guide TABLE 2-1: CHARGING STATES State Description Precharge Charges battery with a low current (usually C/10) until the battery voltage exceeds the defined cutoff voltage. Charge The Charge state has two phases: constant current mode and constant voltage mode. The Charge cycle starts in constant current mode, in which the battery is charged with a constant current (usually C/2) until the battery voltage equals +4.2 V...
Page 19
EQUATION 2-2: CURRENT CALCULATION EXAMPLE FOR 1000 MA ADC maximum Current Shunt Value Amplification Current Counts ----------------------------------------------------------------------------------------------------------------------------------------------------- - ADC Reference 4096 1A Counts ------------------------------------------------------- - 2000 2.048V 2014 Microchip Technology Inc. DS50002321A-page 19...
LI-ION BATTERY CHARGER DEMO BOARD USER’S GUIDE Appendix A. Schematic and Layouts INTRODUCTION This appendix contains the following schematics and layouts for the MCP1632 Single-Cell Li-Ion Battery Charger Demo Board: • Board – Schematic • Board – Top Silk • Board – Top Copper and Silk •...
Res. 39 kΩ 1/10W 1% 0603 Stackpole RMCF0603FT39K0 Electronics, Inc. The components listed in this Bill of Materials are representative of the PCB assembly. The Note: released BOM used in manufacturing uses all RoHS-compliant components. 2014 Microchip Technology Inc. DS50002321A-page 29...
Page 30
MCP1632 Single-Cell Li-Ion Battery Charger Demo Board User’s Guide TABLE B-1: BILL OF MATERIALS (CONTINUED) Quantity Designator Description Manufacturer Manufacturer Part Number Res. 2.7 kΩ 1/10W 5% 0603 Stackpole RMCF0603JT2K70 Electronics, Inc. Res. 91 kΩ 1/10W 5% 0603 Stackpole RMCF0603JT91K0 Electronics, Inc.
Page 31
NOTES: 2014 Microchip Technology Inc. DS50002321A-page 31...
