CommScope 5NPX1006F Installation Instructions Manual

Multi-Beam Panel Antenna 5NPX1006F
Bulleti Bulletin D701-0005 • Revision D • July 2013 page 1 of 8
CommScope Infrastructure Academy offers installation training

General

This instruction sheet contains all necessary information required to assist in the correct installation
of ARGUS Multi-Beam Panel Antennas.
The following symbols can be found next to text outlining important information.

Unpacking

Make sure that the antenna and the accessory items listed below are provided and have not been
damaged during transport.
• Antenna

• Mounting kit

• Installation Instructions (This document)
Do not install near power lines. Power lines,
telephone lines, and guy wires look the same.
Assume any wire or line can electrocute you.
Argus
Please follow the procedure marked with this symbol precisely.
Non-compliance may lead to damage of the product.
Handy tips when installing product.
To make sure no pressure and load on the radome of this antenna in handling and
fixing.
Mounting Kits
Fixed Downtilt
Mechanical Downtilt
Installation Instructions
®
Do not install on a wet or windy day or
when lightning or thunder is in the area.
Do not use metal ladder.
Type
F-042-GL-E
T-045-GL-E
Wear shoes with rubber soles and heels.
Wear protective clothing including a
long-sleeved shirt and rubber gloves.
