About this document

This document describes the use of the above-mentioned product.
Certain aspects of use are described in other documents and must be observed
è 1.1 Further applicable documents.
1.1

Further applicable documents

Document
Description of automation system CPX-E
(CPX-E-SYS)
Instruction manual for automation system CPX-E
(CPX-E-SYS)
Description of controller CPX-E-CEC-...-EP
(CPX-E-CEC-...-EP)
CODESYS Installation and getting started.pdf
CODESYS_OPC_Server_V3_Benutzerhandbuch.pdf
Online help for CODESYS V3
Online help for CODESYS libraries
Instruction manual for operator unit CDSB
Tab. 1 Further applicable documents
All available documents for the product è www.festo.com/pk.
1.2

Product version

This document refers to the following product versions:
Product Programming
CPX-E-CEC-C1-EP with CODESYS V3
CPX-E-CEC-M1-EP with CODESYS V3 and SoftMot-
ion
Tab. 2 Product version
The product version can be identified from the product labelling or with the help
of appropriate software from Festo.
Appropriate software for determining the product version can be found in the
Festo Support Portal è www.festo.com/sp.
Information on using the software can be found in the integrated Help function.
There may be an updated version of this document for these or later product ver-
sions.
• Check whether a corresponding version of this document is available on the
Festo Support Portal è www.festo.com/sp.
Festo AG & Co. KG
Ruiter Straße 82
73734 Esslingen
Germany
+49 711 347-0
www.festo.com
8071211
® , MODBUS ® , WINDOWS ® are registered
Contents
Detailed description of automation system
CPX-E
Instruction manual and important information
on assembly, electrical installation and main-
tenance tasks for an automation system CPX-E
Detailed description of controller
CPX-E-CEC-...-EP
Working with CODESYS
è Installation directory for the software
Detailed information on using the product with
CODESYS V3 and the Festo extensions
Description of the function blocks for an expan-
ded function range of the controller
General functions of the operator unit
Version
Revision 1 or later
Revision 1 or later
1.3

Product labelling

The product labelling is located on the left-hand side of the module. Scanning the
printed Data Matrix Code with an appropriate device opens the Festo Support
Portal, with the information appropriate for the product. Alternatively, the Product
Key (11-digit alphanumeric code on the product labelling) can be entered in the
search field of the Support Portal.
You can find detailed information on the product labelling in the description of the
module è 1.1 Further applicable documents.
1.4

Specified standards

Version status
EN 60529:2013-10
EN 61000-6-2:2005-08
EN 61000-6-4:2007-01
Tab. 3 Standards specified in the document
2 Sicherheit
2.1

Safety instructions

– Take into consideration the legal regulations for the respective destination.
– Use the product only within the defined values è 13 Technical data.
– Observe labelling on the product.
– Observe further applicable documents.
– Store the product in a cool, dry, UV-protected and corrosion-protected envir-
onment. Ensure that storage times are kept to a minimum.
– Before working on the product: switch off the power supply and secure it
against being switched on again.
– Comply with the handling specifications for electrostatically sensitive devices.
– Activate the load voltage first when the system is properly installed, con-
figured and parameterised.
2.2

Intended use

The product described in this document is intended as an autonomous CODESYS
controller for an automation system CPX-E. Interfaces for EtherNet/IP or Mod-
bus TCP are available for communication with a higher-order controller. An Ether-
CAT master interface enables connection to lower-order devices.
Use the product only as follows:
– Use only in an industrial environment. Outside of industrial environments,
e.g. in commercial and mixed-residential areas, it may be necessary to take
measures to suppress interference.
– Use only in combination with modules and components that are permissible
for the respective product variant è www.festo.com/catalogue.
– Only use the product if it is in perfect technical condition.
– Only use the product in original status without unauthorised modifications.
Only the conversions or modifications described in this and the further applic-
able documents are permitted.
2.3

Training of qualified personnel

Installation, commissioning, maintenance and disassembly should only be con-
ducted by qualified personnel.
The qualified personnel must be familiar with installation of electrical control sys-
tems.
Experience of an EtherCAT and EtherNet/IP network and with the CODESYS V3
development kit is required in order to understand this documentation.
3

Further information

– Accessories è www.festo.com/catalogue.
– Spare parts è www.festo.com/spareparts.
4

Service

Contact your regional Festo contact person if you have technical questions
è www.festo.com.
Including the following information will make it easier to process support queries:
• CODESYS project as project archive è menu command in CODESYS V3:
[File] [Project archive] [Save/send archive...]
• Version of the programming environment è menu command in CODESYS V3
[Help] [Information...] [Show detailed version information]
• Controller data è Copy data properties using suitable software from Festo,
e.g. Festo Field Device Tool (FFT).
5 Produktübersicht
5.1

Function

Together with additional CPX-E modules, the product forms an automation system
CPX-E that can be commissioned using CODESYS V3.
Network connection
The product can be integrated directly into a higher-order network. Communica-
tion takes place via EtherNet/IP.
Modbus TCP and standard Ethernet (TCP/IP) are also supported.
EtherCAT Master
EtherCAT Slave devices can be connected to the product.
IEC 60204-1:2014-10
NE 21:2012-05
–
