External Dynamic Brake Kit
30.0
(1.18)
17.0
(0.67)
316.0
(12.44)
13.0
(0.51)
1
L1
L2
L3
3
60.0
(2.36)
mm
(in.)
335.0
(13.19)
AK-R2-091P500
AK-R2-047P500
AK-R2-360P500
I
O
50.8 mm
(2.0 in.)
M5 x 0.8
(#10-24)
61.0
(2.40)
31.0
59.0
(1.22)
(2.32)
386.0
(15.20)
2
0V
DC+
DC–
AC Drive
Installation Instructions
405.0
(15.94)
AK-R2-030P1K2
AK-R2-120P1K2
0V
