Back Panel; Default Settings - Cisco MS200X-24 Quick Start Manual

PoE Lights
(if present)
Link/ACT
Lights
System Light (Green) Lights steady when the switch is powered on,
RESET
Button

Back Panel

Power Port
Grounding
Screw
The fuse is in the neutral (N).
W
ARNING

Default Settings

These are the default settings used when configuring your MS200X switch
for the first time.
Parameter
Username
Password
Switch IP
16
(Amber) These lights are located on the right of the
10/100M RJ-45 Ethernet ports (for MS200X-24P switch
only). Lights steady to indicate that power is being
supplied to a device attached to the corresponding port.
(Green) These lights are located on the left of the
dual-purpose ports. Lights steady when a
10/100/1000 Mbps link between the corresponding port
and other device is detected. Flashes when the port is
passing traffic.
and flashes when booting, performing self tests, and
acquiring an IP address. If the light flashes amber, the
switch has detected a hardware failure, a firmware failure,
and/or a configuration file error.
The RESET button can be used to reboot or reset the
switch. See Returning the MS200X Switch to the
Factory Default Settings
The Power port is used to connect the switch to power.
The grounding screw is used to connect a grounding
cable to the chassis if necessary.
Default Value
cisco
cisco
192.168.1.254
Cisco MS200X Series 10/100 24-Port Ethernet Access Switches
for more information.
