Enter the switch IP address in the address bar and press Enter. For
S 5
TEP
example, http://192.168.1.254.
When the login page appears, enter the username and password.
S 6
TEP
The default username is cisco. The default password is cisco.
Usernames and passwords are both case sensitive.
Click Login.
S 7
TEP
If this is the first time that you have logged on with the default
S 8
TEP
username and password, the Change Password page opens.
Enter a new administrator password and then click Apply.
The Getting Started page displays. You are now ready to
configure the switch. Refer to the
10/100 Ethernet Access Switches Administration Guide
help page for further information.
Make sure that any configuration changes made are saved
N
OTE
before exiting from the web-based interface by clicking on the
Save icon. Exiting before you save your configuration will result in all
changes being lost.

Configuring Your Switch Using the Console Port

To configure the switch using the console port:
Connect a computer to the switch console port using the supplied
S 1
TEP
console cable.
Start a console port utility such as HyperTerminal on the computer.
S 2
TEP
Configure the utility with the following parameters:
S 3
TEP
• 9,600 bits per second
• 8 data bits
• no parity
• 1 stop bit
• no flow control
Enter a username and password. The default username is cisco,
S 4
TEP
and the default password is cisco. Usernames and passwords are
both case sensitive.
If this is the first time that you have logged on with the default
S 5
TEP
username and password, the following message appears:
Cisco MS200X Series 10/100 24-Port Ethernet Access Switches
Cisco MS200X Series 24-Port
or see the
