CompuLab Airtop2 Owner's Manual page 6

Extra Natural airflow (NAF)
features cooling
Redundant power
Trusted platform
module 2.0
I3M (integrated
interactive information
monitor)
Digital power & reset
management using
FPGA
Clamshell opening |
tool-free service
System diagnostics LEDs
Auto-on
BIOS
AMI Aptio V
OS
Windows 10
Professional
Linux Mint
Operating conditions
Power Input voltage range
19V – 24V (+/- 10%)
Power consumption
8W – 240W
Temperature Operating temperature
& humidity range
0°C - 40°C
Relative humidity
5% – 95% non-
condensing
Mechanical specifications
Dimensions Dimensions
& weight 10 cm (W) x 30 cm (H) x
25.5 cm (D)
Weight
6 Kg to 9 Kg*
Housing All aluminum housing
& cooling Natural airflow cooling
(fanless)
Mounting Wall mounting bracket*
DIN-rail mounting
bracket*
www.fit-iot.com
Fanless* natural convection cooling with no moving parts.
* CPU, graphics card and PSU are all passively cooled. No case-fan or any other active cooling is
required.
2x DC inputs with automatic failover.
Firmware TPM +
Optional discrete TPM
An integrated OLED display with navigation keypad for displaying real time power consumption,
temperatures and system information.
Provides precise power-sequencing timing and system voltage monitoring.
Case opens by pressing the top-bar.
RAM modules and HDD-cartridge require no tools for installation*.
* Other devices may require a Phillips screwdriver
Discrete LED indicators of RAM detection, BIOS post HDMI and DisplayPort detection for quick
field diagnostics in case of booting issues.
System boots automatically when power is resumed.
Compatible with other Windows 10 variants.
Compatible with other Linux variants.
Compatible with other hypervisors and operating systems (e.g. ESXi, FreeBSD)
Power consumption depends on
– CPU and graphics card
– System load
– Installed devices
– Connected peripherals
* Weight depends on configuration
* Sold separately
