Memory Mapping for RF-DAC/RF-ADC

PL DDR is divided into four partitions (reserved memory), and each partition is 512 MB. It
can run either RF-DAC/RF-ADC from these partitions. It can run either RF-DAC/RF-ADC
from this partition.
Table 9-2: Memory Mapping for RF-DAC/RF-ADC
Partition
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2018.2) October 1, 2018
Table 9-2 lists partitions, their starting address, and their size.
DDR Start Address
PL 0x410000000
PL 0x418000000
PL 0x420000000
PL 0x428000000
PL 0x430000000
PL 0x438000000
PL 0x440000000
PL 0x448000000
PL 0x450000000
PL 0x458000000
PL 0x460000000
PL 0x468000000
PL 0x470000000
PL 0x478000000
PL 0x480000000
PL 0x488000000
www.xilinx.com
Chapter 9: System Considerations
Size Component
128MB RF-DAC/RF-ADC
128MB RF-DAC/RF-ADC
128MB RF-DAC/RF-ADC
128MB RF-DAC/RF-ADC
128MB RF-DAC/RF-ADC
128MB RF-DAC/RF-ADC
128MB RF-DAC/RF-ADC
128MB RF-DAC/RF-ADC
128MB RF-DAC/RF-ADC
128MB RF-DAC/RF-ADC
128MB RF-DAC/RF-ADC
128MB RF-DAC/RF-ADC
128MB RF-DAC/RF-ADC
128MB RF-DAC/RF-ADC
128MB RF-DAC/RF-ADC
128MB RF-DAC/RF-ADC
