ROADRECORDER® 8000 NVR QUICK INSTALLATION
Typical Configuration
Sensor Wire
Color
Description
Blue
A1
A2
Yellow
A3
Green
A4
Violet
A5
Brown
A6
White
A7
Grey
B1
Orange
Red
B2
B3
B4
B5
B6
B7
P1
Red
P2
Black
Fuse Requirements
P1
Red
Main Power (7.5 amp)
B1
Orange
Ignition (3 amp)
RoadRecorder 8000 NVR
Brake
Right Turn
Left Turn
Head Lights
Front Door
Wheel Chair
Stop Request
Ignition
Open
Open
Open
Open
Open
Open
Main Power
Main Ground
