Cutouts For Monogram Cooktops - Monogram ZVB36 Installation Instructions Manual

ZEU30R
Digital Cooktops
with 30" Vent
Countertop Cutout: Requires 23-3/8" (B,W) 23-1/2"
(SS) flat countertop surface. Requires 24-3/4" (B,W) and
24-7/8" (SS) total countertop depth.
ZEU36R
Digital Cooktops
with 36" Vent
21-3/4"
Cutout
Depth 19-1/8"
Countertop Cutout: Requires 22-7/8" (B,W) 23" (SS)
flat countertop surface. Requires 24-1/4" (B,W) and
24-3/8" (SS) total countertop depth.
29-7/8" (SS)
29-3/4" (B,W)
22-1/4"
28-1/2"
Cutout
Cooktop Area Cutout
Depth
5/8" Cooktop Overlap
(1-1/8" at Center)
2-1/2" Min.
Front Edge
Clearance to Cutout
of Countertop
1-3/4" Min. Cooktop Cutout to Rear
36-1/8" (SS)
36" (B,W)
2-3/4"
34"
Cooktop and Vent Cutout
Cooktop
5/8" Cooktop Overlap
Cutout
Depth (1-1/8" at Center)
2-1/2" Min.
Front Edge
Clearance to Cutout
of Countertop
Installation Preparation
1-3/4" Min. Cooktop Cutout to Rear
Vertical Combustible Surface
1/4" Overlap
1/8" Gap
23-1/2" (SS)
23-3/8" (B,W)
Total Flat
Surface
Required
at Center
2" Min. Cutout
to Side Walls
Vertical Combustible Surface
1/4" Overlap
1/8" Gap
23" (SS)
22-7/8" (B,W)
Total Flat
Surface
Required
2" Min. Cutout
to Side Walls
Downdraf t Vent Systems
2-1/2" to
1-7/8"
Cutout
ZEU30 Cooktop
20-3/8"
3/4"
DOWNDRAFT VENT
22-3/4" to Back Wall
22" to Support Rail
24-3/4"
Cabinet: Requires 23" inside cabinet
depth.
– See Creative Solutions, install in an
island or move cabinet base forward.
2-1/2" to
1-7/8"
Cutout
ZEU36 Cooktop
19-7/8"
3/4"
DOWNDRAFT VENT
22-3/4" to Back Wall
22" to Support Rail
24-3/4"
Cabinet: Requires 22-1/2" inside
cabinet depth.
–Remove rear support rail.
3/4"
Thick
Support
Rail
3/4"
Thick
Support
Rail
7
